AVR-4802/AVC-A11SR
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks Q'ty
CW131 205 0942 006 13P connector socket (TUC-P) 1
CW155 205 0885 040 15P connector socket (TUC-P) 1
CX49 205 0884 083 4P connector base (TUC-P) 1
CX231 205 1052 005 23P FFC base (9604F) 1
CY46 205 0343 045 4P connector base (KR-PH)
AVR MODEL ONLY
1
CY95 205 0343 090 9P connector base (KR-PH) 1
CY151 205 0375 055 15P connector base (KR-PH) 1
FB101 247 2018 903 Carbon chip 0 ohm 1/16W 1
FB103,104 247 2018 903 Carbon chip 0 ohm 1/16W 2
FB105-107 235 0130 903 Chip emifil (11A121) 3
FB305 247 2018 903 Carbon chip 0 ohm 1/16W 1
FB306 235 0130 903 Chip emifil (11A121) 1
FB307 247 2018 903 Carbon chip 0 ohm 1/16W 1
FB308 235 0130 903 Chip emifil (11A121) 1
FB309 247 2018 903 Carbon chip 0 ohm 1/16W 1
FB310,311 235 0130 903 Chip emifil (11A121) 2
FB312-316 247 2018 903 Carbon chip 0 ohm 1/16W 5
FB317 235 0130 903 Chip emifil (11A121) 1
FB319 247 2018 903 Carbon chip 0 ohm 1/16W 1
FB320 235 0130 903 Chip emifil (11A121) 1
FB501-503 247 2018 903 Carbon chip 0 ohm 1/16W 3
FB801 235 0049 900 Beads inductor 1
FB803 235 0049 900 Beads inductor
AVR MODEL ONLY
1
FB804 235 0049 900 Beads inductor
AVR MODEL ONLY
1
FB805 235 0130 903 Chip emifil (11A121) 1
FB806 235 0049 900 Beads inductor 1
FB807,808 235 0130 903 Chip emifil (11A121) 2
FB809 235 0049 900 Beads inductor 1
FB810,811 235 0130 903 Chip emifil (11A121) 2
FB812 235 0049 900 Beads inductor 1
FB814-817 235 0049 900 Beads inductor 4
JK101 204 8577 014 3P pin jack (F-GND NI)
AVR MODEL ONLY
1
204 8577 001 3P pin jack (F-GND NI)
AVC MODEL ONLY
1
JK201,202 204 8545 004 4P pin jack (GND)
AVR MODEL ONLY
2
204 8514 006 4P pin jack (GND)
AVC MODEL ONLY
2
L101-103 235 0060 905 Inductor 2.2
µ
H3
S801 212 0459 005 4P dip switch 1
S802 212 0460 007 2P dip switch 1
S803 212 5604 910 Tact switch 1
X801,802 399 0624 001 Crystal 15.0 MHz 2
C806 254 4538 900 Electrolytic 10
µ
F/16V
CE04W1C100MT SMG/RE3
C807 257 0512 903 Ceramic chip 0.1
µ
F/25V CK73F1E104ZT
C808 254 4538 900 Electrolytic 10
µ
F/16V
CE04W1C100MT SMG/RE3
C809 257 0512 903 Ceramic chip 0.1
µ
F/25V CK73F1E104ZT
C810 257 0503 967 Ceramic chip 15pF/50V CC73CH1H150JT
C811 257 0512 903 Ceramic chip 0.1
µ
F/25V CK73F1E104ZT
C812 257 0503 967 Ceramic chip 15pF/50V CC73CH1H150JT
C813 257 0511 904 Ceramic chip 0.01
µ
F/50V CK73F1H103ZT
C814 254 4533 921 Electrolytic 100
µ
F/6.3V
CE04W0J101MT SMG/RE3
C815 257 0511 904 Ceramic chip 0.01
µ
F/50V CK73F1H103ZT
C816 254 4538 900 Electrolytic 10
µ
F/16V
CE04W1C100MT SMG/RE3
C817,818 257 0512 903 Ceramic chip 0.1
µ
F/25V CK73F1E104ZT
C819 254 4538 939 Electrolytic 47
µ
F/16V
CE04W1C470MT SMG/RE3
C820 254 4538 900 Electrolytic 10
µ
F/16V
CE04W1C100MT SMG/RE3
C821 254 4538 939 Electrolytic 47
µ
F/16V
CE04W1C470MT SMG/RE3
C822 254 4538 900 Electrolytic 10
µ
F/16V
CE04W1C100MT SMG/RE3
C823 257 3013 933 Ceramic chip 0.1
µ
F/50V CF73=1H104JT
(ECHUC9)
C824 257 0512 903 Ceramic chip 0.1
µ
F/25V CK73F1E104ZT
C825 254 4533 947 Electrolytic 330
µ
F/6.3V
CE04W0J331MT SMG/RE3
C826 254 4538 900 Electrolytic 10
µ
F/16V
CE04W1C100MT SMG/RE3
C827 257 0512 903 Ceramic chip 0.1
µ
F/25V CK73F1E104ZT
C828 254 4522 903 Electrolytic 4.7
µ
F/35V
CE04W1V4R7MT SMG/RE3
C829 257 0511 904 Ceramic chip 0.01
µ
F/50V CK73F1H103ZT
C830,831 257 0503 967 Ceramic chip 15pF/50V CC73CH1H150JT
C832 257 0512 903 Ceramic chip 0.1
µ
F/25V CK73F1E104ZT
C833 254 4533 947 Electrolytic 330
µ
F/6.3V
CE04W0J331MT SMG/RE3
C834 254 4538 900 Electrolytic 10
µ
F/16V
CE04W1C100MT SMG/RE3
C835 257 0512 903 Ceramic chip 0.1
µ
F/25V CK73F1E104ZT
C836 257 0511 904 Ceramic chip 0.01
µ
F/50V CK73F1H103ZT
C837 259 0007 702 Back up cap. 8200
µ
F/5.5V SB CAP==822=C
C838 257 0512 903 Ceramic chip 0.1
µ
F/25V CK73F1E104ZT
C839 254 4533 934 Electrolytic 220
µ
F/6.3V
CE04W0J221MT SMG/RE3
C840 257 0509 929 Ceramic chip 1000pF/50V CK73B1H102KT
AVR MODEL ONLY
C846,847 257 0509 929 Ceramic chip 1000pF/50V CK73B1H102KT
AVR MODEL ONLY
C848 257 0516 909 Ceramic chip 0.022
µ
F/25V CK73B1E223KT
AVR MODEL ONLY
C852,853 257 0516 909 Ceramic chip 0.022
µ
F/25V CK73B1E223KT
OTHER PARTS GROUP Q'ty
CW23 203 2408 005 2P SCN-SCN connector cord 1
CW71 205 0942 022 7P connector socket (TUC-P) 1
CW81 205 0885 095 8P connector socket (TUC-P)
AVR MODEL ONLY
1
CW8283 205 0885 095 8P connector socket (TUC-P) 2
CW91 205 0885 037 9P connector socket (TUC-P) 1
CW93 205 0885 037 9P connector socket (TUC-P) 1
CW96 205 0885 037 9P connector socket (TUC-P) 1
CW111,112 205 0885 066 11P connector socket (TUC-P) 2
