AVR-4802/AVC-A11SR
PARTS LIST OF P.W.B. UNIT
1U-3350 DSP UNIT ASS'Y
Ref. No. Part No. Part Name Remarks
SEMICONDUCTORS GROUP
IC101 262 2572 901 IC SN74LVU04APW-EL2
IC102-104 262 2944 908 IC SN74HC151APW-EL2
IC105 262 2945 907 IC SN74HC153APW-EL2
IC106 262 2861 900 IC 74VHC123AMTCX
IC107 262 2870 904 IC 74LVX157MTC
IC108 262 2519 906 IC SN74LV00APW-EL2
IC109 262 2980 904 IC SN74AHC1G04DBV
IC110 262 2557 900 IC SN74LV14APW-EL2
IC111 262 2675 015 IC LC89055W-RA8
IC112 262 2781 909 IC SN74LV4040APW
IC113 399 0575 008 Crystal 12.287 MHz
IC114 262 2772 905 IC AK5353
IC115 263 0934 900 IC BA4510F-E2
IC116 269 0178 007 Optical connector GP1F37R1
IC117 263 0896 909 IC NJM2068MD-T1
IC118-121 269 0178 007 Optical connector GP1F37R1
IC122,123 269 0177 008 Optical connector GP1F38T2
IC124 262 2557 900 IC SN74LV14APW-EL2
IC125 262 2517 908 IC SN74LV08APW-EL2
IC201-204 263 0896 909 IC NJM2068MD-T1
IC301 262 2768 906 IC AD1854KRSRL
IC302 263 0896 909 IC NJM2068MD-T1
IC303 262 2768 906 IC AD1854KRSRL
IC304 263 0896 909 IC NJM2068MD-T1
IC305 262 2768 906 IC AD1854KRSRL
IC306 263 0896 909 IC NJM2068MD-T1
IC307 262 2768 906 IC AD1854KRSRL
IC308 263 0896 909 IC NJM2068MD-T1
IC309,310 263 1100 005 IC KIA7805API
IC471 263 0896 909 IC NJM2068MD-T1
IC501,502 262 2853 002 IC ADSP-21065L
IC504 GEN5216 DSP1 CPU SUB ASS'Y AVR MODEL ONLY
2622779005
LH28F800BVE-BTL90
GEN5300 DSP1 CPU SUB ASS'Y 2 AVC MODEL ONLY
2622779005
LH28F800BVE-BTL90
IC505,506 262 2855 000 IC 16M SDRAM TSOP-8 H/W
IC507 GEN5217 DSP2 CPU SUB ASS'Y AVR MODEL ONLY
2622779005
LH28F800BVE-BTL90
GEN5301 DSP2 CPU SUB ASS'Y 2 AVC MODEL ONLY
2622779005
LH28F800BVE-BTL90
IC508,509 262 2855 000 IC 16M SDRAM TSOP-8 H/W
IC510 262 2854 904 IC HG-8002JA33MHZPCCX
IC511 262 2519 906 IC SN74LV00APW-EL2
IC512 262 2781 909 IC SN74LV4040APW
IC513 262 2519 906 IC SN74LV00APW-EL2
Ref. No. Part No. Part Name Remarks
IC514 262 2780 900 IC SN74AHCT541PW
IC515 262 2729 903 IC SN74LV02APW-EL2
IC516 262 2606 903 IC SN74AHCT573PW
IC517 262 2682 901 IC SN74LV573ANS-EL2
IC518 262 2641 900 IC SN74LV541APW
IC519 262 2729 903 IC SN74LV02APW-EL2
IC520 262 2606 903 IC SN74AHCT573PW
IC521 262 2682 901 IC SN74LV573ANS-EL2
IC522 262 2641 900 IC SN74LV541APW
IC523 262 2948 904 IC SN74LV86APW
IC526,527 263 1048 002 IC BA033T
IC801 GEN5215 SUB CPU ASS'Y AVR MODEL ONLY
262 2784 003
TMP95FY64F
GEN5299 SUB CPU ASS'Y 2 AVC MODEL ONLY
2622784003
TMP95FY64F
IC802 GEN5214 MAIN CPU SUB ASS'Y AVR MODEL ONLY
262 2784 003
TMP95FY64F
GEN5298 MAIN CPU SUB ASS'Y 2 AVC MODEL ONLY
262 2784 003
TMP95FY64F
IC803 262 2641 900 IC SN74LV541APW
IC805 262 2785 905 IC SN74LV125APW
IC806 262 2786 904 IC SN74LV126APW
TR102,103 269 0192 902
Transistor KRC102S-RTK(10K-10K)
TR104,105 269 0184 907 Transistor KRA102S-RTK
TR107,108 273 0460 905 Transistor KTC2875B-RTK
TR301-303 269 0184 907 Transistor KRA102S-RTK
TR305-308 273 0460 905 Transistor KTC2875B-RTK
TR309-311 269 0184 907 Transistor KRA102S-RTK
TR313-316 273 0460 905 Transistor KTC2875B-RTK
TR317-319 269 0184 907 Transistor KRA102S-RTK
TR321-324 273 0460 905 Transistor KTC2875B-RTK
TR325-327 269 0184 907 Transistor KRA102S-RTK
TR329-332 273 0460 905 Transistor KTC2875B-RTK
TR471,472 273 0460 905 Transistor KTC2875B-RTK
TR501,502 269 0184 907 Transistor KRA102S-RTK
TR801 269 0192 902
Transistor KRC102S-RTK(10K-10K)
TR802 271 0299 905 Transistor 2SA1505Y-RTK
TR803 269 0192 902
Transistor KRC102S-RTK(10K-10K)
TR804 269 0184 907 Transistor KRA102S-RTK
TR806 269 0192 902
Transistor KRC102S-RTK(10K-10K)
TR807 269 0184 907 Transistor KRA102S-RTK
TR808 269 0193 901
Transistor KRC104S-RTK(47K-47K)
TR809 273 0384 900 Transistor 2SC2412KT96(S)
TR810 269 0192 902
Transistor KRC102S-RTK(10K-10K)
