54
AVR-4802/AVC-A11SR
Ref. No. Part No. Part Name Remarks Q'ty Ref. No. Part No. Part Name Remarks
JK403 205 1202 004 6P SP terminal 1
JK404 205 1201 005 4P SP terminal 1
JK701-704 204 8607 010 3P pin jack (COMP-NI)
AVR MODEL ONLY
4
204 8607 007 3P pin jack (COMP-AU)
AVC MODEL ONLY
JK951 204 8217 031 Headphone jack (BK(AU)) 1
L201,202 235 0060 934 Inductor 47
µ
H2
RL201,202 214 0212 002 Relay TV-8 (DLS1U) 2
RL701-706 214 0208 003 Relay (NA24W-K) 6
S421 212 0373 000 Rotary encoder EC16B 1
S422,423 212 5604 910 Tact switch 2
S901-918 212 5604 910 Tact switch 18
S920 212 0373 000 Rotary encoder EC16B 1
S922,923 212 5604 910 Tact switch 2
T201 233 6373 001 Power trans (SUB/E3)
AVR&TAIWAN R.O.C.
MODEL ONLY
1
233 6374 000 Power trans (SUB/E2)
EUROPE, ASIA,
HONG KONG
MODEL ONLY
1
233 6375 009 Power trans (SUB/CH)
CHINA, KOREA
MODEL ONLY
1
T202 233 6385 002 Power trans (MINI/E3)
AVR&TAIWAN R.O.C.
MODEL ONLY
1
233 6386 001 Power trans (MINI/E2)
EUROPE, ASIA,
HONG KONG
MODEL ONLY
1
233 6387 000 Power trans (MINI/CH)
CHINA, KOREA
MODEL ONLY
1
W202,203 205 0864 029 M3 screw terminal 2
W205,206 205 0864 029 M3 screw terminal 2
W744 203 0629 006 1P contact Ass’y 1
W781-787 205 1034 010 M3 Screw terminal 7
1U-3356 AMP UNIT ASS'Y
SEMICONDUCTORS GROUP
TR101,102 273 0459 903 Transistor KTC2874B-AT
TR103-106 271 0094 919 Transistor 2SA970(BL)TPE2
TR107,108 273 0453 006 Transistor 2SC4001(M/L)
TR109,110 271 0304 007 Transistor 2SA1546(M/L)
TR111,112 273 0453 006 Transistor 2SC4001(M/L)
TR113,114 273 0445 001 Transistor 2SC4495
TR115,116 273 0458 904 Transistor 2SC/KTC3200BL-AT
TR117,118 269 0018 905
Transistor DTC143ES(4.7K-4.7K)T
TR202 273 0459 903 Transistor KTC2874B-AT
TR204 271 0094 919 Transistor 2SA970(BL)TPE2
TR206 271 0094 919 Transistor 2SA970(BL)TPE2
TR208 273 0453 006 Transistor 2SC4001(M/L)
TR210 271 0304 007 Transistor 2SA1546(M/L)
TR212 273 0453 006 Transistor 2SC4001(M/L)
TR214 273 0445 001 Transistor 2SC4495
TR216 273 0458 904 Transistor 2SC/KTC3200BL-AT
TR218 269 0018 905
Transistor DTC143ES(4.7K-4.7K)T
TR301,302 273 0459 903 Transistor KTC2874B-AT
TR303-306 271 0094 919 Transistor 2SA970(BL)TPE2
TR307,308 273 0453 006 Transistor 2SC4001(M/L)
TR309,310 271 0304 007 Transistor 2SA1546(M/L)
TR311,312 273 0453 006 Transistor 2SC4001(M/L)
TR313,314 273 0445 001 Transistor 2SC4495
TR315,316 273 0458 904 Transistor 2SC/KTC3200BL-AT
TR317,318 269 0018 905
Transistor DTC143ES(4.7K-4.7K)T
TR351,352 269 0018 905
Transistor DTC143ES(4.7K-4.7K)T
TR401,402 273 0459 903 Transistor KTC2874B-AT
TR403-406 271 0094 919 Transistor 2SA970(BL)TPE2
TR407,408 273 0453 006 Transistor 2SC4001(M/L)
TR409,410 271 0304 007 Transistor 2SA1546(M/L)
TR411,412 273 0453 006 Transistor 2SC4001(M/L)
TR413,414 273 0445 001 Transistor 2SC4495
TR415,416 273 0458 904 Transistor 2SC/KTC3200BL-AT
TR417,418 269 0018 905
Transistor DTC143ES(4.7K-4.7K)T
TR503-506 271 0301 903 Transistor 2SA/KTA1268BL-AT
D101,102 276 0432 903 Diode 1SS270A TE (TAPE)
D105-112 276 0432 903 Diode 1SS270A TE (TAPE)
D202 276 0432 903 Diode 1SS270A TE (TAPE)
D206 276 0432 903 Diode 1SS270A TE (TAPE)
D208 276 0432 903 Diode 1SS270A TE (TAPE)
D210 276 0432 903 Diode 1SS270A TE (TAPE)
D212 276 0432 903 Diode 1SS270A TE (TAPE)
D301,302 276 0432 903 Diode 1SS270A TE (TAPE)
D305-312 276 0432 903 Diode 1SS270A TE (TAPE)
