52
AVR-4802/AVC-A11SR
Ref. No. Part No. Part Name Remarks Q'ty Ref. No. Part No. Part Name Remarks
1U-3355 REG UNIT ASS'Y
OTHER PARTS GROUP
CW45 203 6374 025 4P KR-DA connector cord 1
CW49 205 0885 082 4P connector socket (TUC-P) 1
CW55 205 0885 008 5P connector socket (TUC-P) 1
CW57 203 8211 034 5P KR-DA connector cord 1
CW79 204 2513 087 7P KR-DA connector cord 1
CX40 205 0884 083 4P connector base (TUC-P) 1
CX41 205 0355 046 4P KR connector base (L) 1
CX46 205 0343 045 4P connector base (KR-PH)
AVR MODEL ONLY
1
CX51 205 0884 009 5P connector base (TUC-P) 1
CX54,55 205 0884 009 5P connector base (TUC-P) 2
CX61-63 205 0943 018 6P connector base (TUC-P) 3
CX71 205 0943 021 7P connector base (TUC-P) 1
CX73 205 0943 021 7P connector base (TUC-P) 1
CX75 205 0943 021 7P connector base (TUC-P) 1
CX76,77 205 0355 075 7P KR connector base (L) 2
CX81 205 0884 096 8P connector base (TUC-P)
AVR MODEL ONLY
1
CX82,83 205 0884 096 8P connector base (TUC-P) 2
CX91 205 0884 038 9P connector base (TUC-P) 1
CX93 205 0884 038 9P connector base (TUC-P) 1
CX96 205 0884 038 9P connector base (TUC-P) 1
CX101 205 0884 054 10P connector base (TUC-P) 1
CX111-113 205 0884 067 11P connector base (TUC-P) 3
CX116 205 0884 067 11P connector base (TUC-P) 1
CX131,132 205 0943 005 13P connector base (TUC-P) 2
CX135 205 0943 005 13P connector base (TUC-P) 1
CX155-159 205 0884 041 15P connector base (TUC-P) 5
CX502 205 1153 001 9P S SUB connector 1
CX941,942 205 0343 045 4P connector base (KR-PH) 2
CX945 205 0884 083 4P connector base (TUC-P) 1
CX952 205 0770 045 15P FFC base (SIDE)
AVR MODEL ONLY
1
CY231 205 1052 005 23P FFC base (9604F) 1
FB504,505 235 0130 903 Chip emifil (11A121) 2
FB901,902 235 0049 900 Beads inductor
AVR MODEL ONLY
2
FL101 393 8033 007 FLD (CM1690C) 1
JK301 204 8617 013 2P pin jack 1
JK401,402 204 8540 009 4P pin jack
AVR MODEL ONLY
2
204 8540 012 4P pin jack
AVC MODEL ONLY
2
JK501 204 8289 001 DC Power jack
AVR MODEL ONLY
1
JK502,503 204 8260 004 Mini jack
AVR MODEL ONLY
2
L101 235 0060 989 Inductor 120
µ
H1
W513,514 205 1034 007 M3 Screw terminal
AVR MODEL ONLY
2
W515 205 1034 007 M3 Screw terminal 1
SEMICONDUCTORS GROUP
IC202 263 1065 001 IC PQ15RW11
IC203 263 1100 018 IC KIA7806API
IC204 268 0073 905 IC ICP-N15T
IC205 263 1094 001 IC BA08ST
TR201 273 0303 910 Transistor 2SC1740S(S)-T
TR202 271 0302 009 Transistor 2SA/KTA1659A(O/Y)
TR203 269 0040 902
Transistor DTC144ES (47K-47K)T
TR204 269 0020 906
Transistor DTC114ES(10K-10K)T
TR205,206 273 0303 910 Transistor 2SC1740S(S)-T
TR207 271 0192 905 Transistor 2SA933S(S)TP
TR208 271 0117 906 Transistor 2SA1020(Y)TPE6
TR210 269 0020 906
Transistor DTC114ES(10K-10K)T
TR211 272 0158 007 Transistor 2SB/KTB778(R/O)
TR212 273 0303 910 Transistor 2SC1740S(S)-T
TR214 269 0020 906
Transistor DTC114ES(10K-10K)T
TR701-703 269 0018 905
Transistor DTC143ES(4.7K-4.7K)T
D202 276 0432 903 Diode 1SS270A TE (TAPE)
D204-206 276 0704 903 Diode 1SR35-400A(T93X)
D208-210 276 0704 903 Diode 1SR35-400A(T93X)
D211 276 0432 903 Diode 1SS270A TE (TAPE)
D212,213 276 0704 903 Diode 1SR35-400A(T93X)
D214 276 0432 903 Diode 1SS270A TE (TAPE)
D215,216 276 0704 903 Diode 1SR35-400A(T93X)
D217 276 0432 903 Diode 1SS270A TE (TAPE)
D304 276 0338 007 Diode S4VB20F
D306 276 0338 007 Diode S4VB20F
D703-705 276 0432 903 Diode 1SS270A TE (TAPE)
ZD201 276 0485 905 Zener diode HZS36-1TD
ZD202 276 0467 907 Zener diode HZS9A-1TD
ZD203 276 0479 908 Zener diode HZS20-1TD
RESISTORS GROUP
R204 244 2051 974 Metal oxide 1 kohm 1W(NB)
RS14B3A102JNBST(S)
R205 241 2387 940 Carbon film 4.7 ohm 1/4W(NB) RD14B2E4R7JNBST
R214 241 2379 987 Carbon film 1 kohm 1/4W(NB) RD14B2E102JNBST
R223 241 2376 919 Carbon film 30 ohm 1/4W(NB) RD14B2E300JNBST
R225,226 243 2091 009 Winding 33 ohm 10W RW78A4A330J=(UL)
R227 242 2009 001 Composition 1/2W RC05GF2H225K(UL)
CAPACITORS GROUP
C201 254 4313 918 Electrolytic 10
µ
F/50V
CE04W1H100MT(ASF)
C202 254 4569 911 Electrolytic 47
µ
F/25V
CE04W1E470MT(RE3)
C204,205 254 4524 943 Electrolytic 1
µ
F/50V
CE04W1H010MT SMG/RE3
C206 254 4313 918 Electrolytic 10
µ
F/50V
CE04W1H100MT(ASF)
