Denon AVR-4208 Service Manual

Ref. No. Part No. Part Name Remarks Q'ty
48 144 2766 008 Door AVR MODEL ONLY 1
48 144 2766 024 Door AVC BLACK MODEL 1
48 144 2766 037 Door AVC GOLD MODEL 1
49 401 0184 200 Hinge (L) GOLD MODEL 1
49 401 0184 213 Hinge (L) BLACK MODEL 1
50 401 0185 209 Hinge (R) GOLD MODEL 1
50 401 0185 212 Hinge (R) BLACK MODEL 1
51 441 1900 009 Plate 1
52 441 1906 003 Spacer 1
53 441 1905 004 Spacer 1
54 146 2248 205 Inner panel ass’y AVR MODEL ONLY 1
54 146 2248 221 Inner panel ass’y AVC BLACK MODEL 1
54 146 2248 234 Inner panel ass’y AVC GOLD MODEL 1
55 412 4177 006 VR bracket 1
56 009 0191 026 23P FFC cable 1
57 445 8004 007 Wire clamper 10
58 112 0877 002 Knob ass’y(M) BLACK MODEL 1
58 112 0877 015 Knob ass’y(M) GOLD MODEL 1
59 113 1792 105 Power knob ass’y BLACK MODEL 1
59 113 1792 118 Power knob ass’y GOLD MODEL 1
60 112 0879 000 Knob ass’y(F) BLACK MODEL 1
60 112 0879 013 Knob ass’y(F) GOLD MODEL 1
61 112 0881 001 Knob maru ass’y BLACK MODEL 1
61 112 0881 014 Knob maru ass’y GOLD MODEL 1
62 009 0191 013 15P FFC cable AVR MODEL ONLY 1
63 461 0639 003 Rubber sheet AVR MODEL ONLY 1
64 102 0649 000 Top cover BLACK MODEL 1
64 102 0649 013 Top cover GOLD MODEL 1
65 461 0501 005 Rubber sheet 2
66 461 0573 046 Rubber sheet 4
67 461 0573 059 Rubber sheet 2
68 513 1581 011 Serial no. sheet 1
68 513 2481 000 Serial no. sheet (T) TAIWAN R.O.C. 1
MODEL ONLY
69 GEN5251 License sub Ass’y 1
70 GEN4990-6 Rating sub Ass’y AVR MODEL ONLY 1
70 GEN4990-7 Rating sub Ass’y EUROPE,ASIA 1
MODEL ONLY
70 GEN4990-8 Rating sub Ass’y TAIWAN R.O.C. 1
MODEL ONLY
71 513 3286 000 Caution label 1
72 204 6694 009 11P PH-PH con.cord CN114 1
73 204 6362 001 15P KR-KR ribbon 70 CN151 1
74 203 5263 001 3P VH-VH con cord CN22 1
AVR&TAIWAN R.O.C.
MODEL ONLY
74 203 5252 012 3P VH con ass’y CN22 1
EUROPE,ASIA
MODEL ONLY
75 203 6385 072 4P KR-KR ribbon 200 CN41 1
76 203 6564 000 4P PH-PH con.cord CN46 1
AVR MODEL ONLY
77 204 2895 006 9P PH-PH con.cord CN92 1
Ref. No. Part No. Part Name Remarks Q'ty
78 204 2549 006 9P KR-KR ribbon 70 CN95 1
79 203 5234 027 3P VH-VH con cord CN21 1
AVC MODEL ONLY
80 513 2482 009 Caution label (T) TAIWAN R.O.C. 1
MODEL ONLY
81 513 3497 019 Kolin rating TAIWAN R.O.C. 1
MODEL ONLY
82 415 0845 001 SP rivet EUROPE,ASIA,CHINA
MODEL ONLY 18
90 203 3942 007 AC OUTLET (E2) EUROPE,ASIA
MODEL ONLY 1
SCREWS
101 470 0051 009 3X8 CPS(SW,W) ZNP 20
102 473 7002 018 3X8 CBTS (S)-Z 44
103 473 7003 017 3X8 CFTS (S)-B 2
104 473 7007 000 4X8 CBTS (S)-B 4
105 473 7015 005 3X6 CBTS(S)-B AVR MODEL ONLY 24
105 473 7015 005 3X6 CBTS(S)-B AVC MODEL ONLY 19
106 473 7015 018 3X8 CBTS (S)-B 2
107 473 7026 007 4X6 CBTS (S)-B 18
108 473 7500 015 3X8 CBTS (P)-Z 29
109 473 7501 030 3X20 CBTS (P)-Z 4
110 473 7505 007 2.6X8 CBTS (P)-Z 4
111 473 7514 001 Special screw 1
112 473 8034 030 3X10 CBTS(B)-Z 12
113 477 0064 107 Fixing screw AVR&TAIWAN R.O.C.
MODEL ONLY 55
113 477 0064 107 Fixing screw
EUROPE,ASIA,CHINA,
KOREA MODEL ONLY
53
114 477 0153 021 3X16 CPTS(B) SW W 37
115 477 0263 005 3P. Swelling screw BLACK MODEL 9
115 477 0263 018 3P. Swelling screw GOLD MODEL 9
116 473 7500 028 3X8 CFTS (P)-Z 2
PARTS LIST OF EXPLODED VIEW
Ref. No. Part No. Part Name Remarks Q'ty Ref. No. Part No. Part Name Remarks Q'ty
1 1U-3350 DSP unit Ass’y AVR MODEL ONLY 1
1U-3350 A DSP unit Ass’y AVC MODEL ONLY
2 1U-3351 Audio unit Ass’y AVR MODEL ONLY 1
1U-3351 A Audio unit Ass’y AVC MODEL ONLY
2-1 Audio IN unit
2-2 S-Video unit
3 1U-3353 Cvideo&Reg unit Ass’y AVR MODEL ONLY 1
1U-3353 A Cvideo&Reg unit Ass’y TAIWAN R.O.C
MODEL ONLY
1U-3353 B Cvideo&Reg unit Ass’y EUROPE,ASIA,CHINA
KOREA MODEL ONLY
3-1 C Video & REG. unit
3-2 OSD unit
3-3 Master VR unit
3-4 AC Outlet unit AVR&TAIWAN R.O.C.
MODEL ONLY
3-5 P.SW unlock unit AVR MODEL ONLY
3-6 P.SW lock unit AVC MODEL ONLY
4 1U-3354 Connect unit Ass’y AVR MODEL ONLY 1
1U-3354 A Connect unit Ass’y AVC MODEL ONLY
4-1 Connect L unit
4-2 Connect R unit
4-3 FLD unit
4-4 Phono unit
4-5 PH Connect unit
4-6 232C unit
4-7 232C CON. unit
4-8 Remote unit AVR MODEL ONLY
4-9 Joint unit
5 1U-3355 REG. unit Ass’y AVR MODEL ONLY 1
1U-3355 A REG. unit Ass’y TAIWAN R.O.C.
MODEL ONLY
1U-3355 B REG. unit Ass’y EUROPE,ASIA,CHINA
KOREA MODEL ONLY
5-1 SP L unit
5-2 SP R unit
5-3 Primaly unit
5-4 Input SEL unit
5-5 COMP.Video unit
5-6 H/P unit
5-7 SP R GND unit
5-8 SP L GND unit
5-9 Tact unit
6 1U-3356 AMP unit Ass’y 1
6-1 AMP L unit
6-2 AMP R unit
6-3 TR114 unit
6-4 TR113 unit
6-5 TR214 unit
6-6 TR213 unit
6-7 TR314 unit
6-8 TR313 unit
6-9 TR414 unit
6-10 TR413 unit
7 411 1985 007 Front chassis 1
8 513 3675 006 Fuse caution AVR MODEL ONLY 1
9 513 3676 005 Fuse & Ic caution AVR MODEL ONLY 1
10 412 4797 004 Head phone bracket 1
11 441 1793 009 Snap plate 1
12 411 1987 102 Side chassis 2
13 445 0048 016 Cord holder (L50) 3
14 414 0937 107 Shield sheet 1
15 414 0926 008 Shield plate 1
16 105 1376 203 Back panel AVR MODEL ONLY 1
16 105 1376 229 Back panel (E2/E1) EUROPE,ASIA 1
MODEL ONLY
16 105 1376 232 Back panel (E1C) CHINA MODEL ONLY 1
16 105 1376 245 Back panel (EUT) TAIWAN R.O.C 1
MODEL ONLY
16 105 1376 258 Back panel (E1K) KOREA MODEL ONLY 1
17 205 1116 006 Terminal ass 1
18 203 3970 008 AC inlet 1
19 203 2406 007 2C wire ass’y 1
20 342 0030 000 Ferrite core 1
21 445 8004 007 Wire clamper 1
22 216 0113 000 Am fm tuner(E3) AVR MODEL ONLY 1
23 412 4798 003 Trans plate 1
24 412 2762 002 P.W.B.holder 4
25 415 0469 047 Flexible bush 1
26 412 2814 028 Card spacer(L=10) 1
27 105 1377 008 Bottom cover 1
28 513 8266 009 Dangerous mark AVR MODEL ONLY 1
29 104 0194 289 Foot ass’y 4
30 417 0612 104 Power radiator 1
31 272 0159 006 MP1715(O/P/Y)LF(202) 4
32 274 0199 004 MN1715(O/P/Y)LF(202) 4
33 412 4799 109 Radiator bracket(A) 1
34 412 4799 112 Radiator bracket(A) 1
35 412 4800 001 Radiator bracket(B) 2
36 417 0612 104 Power radiator 1
37 272 0159 006 MP1715(O/P/Y)LF(202) 3
38 274 0199 004 MN1715(O/P/Y)LF(202) 3
39 412 4799 109 Radiator bracket(A) 1
40 412 4799 112 Radiator bracket(A) 1
41 412 4800 001 Radiator bracket(B) 2
42 233 6370 004 Power trans(main/E3) AVR&TAIWAN R.O.C.
MODEL ONLY 1
42 233 6371 003 Power trans(main/E2) EUROPE,ASIA
MODEL ONLY 1
42 233 6372 002 Power trans(main/CH) CHINA,KOREA
MODEL ONLY 1
43 513 3333 005 Label (trans) 1
44 445 0048 016 Cord holder (L50) 2
45 144 2765 106 Front panel ass’y AVR MODEL ONLY 1
45 144 2765 122 Front panel ass’y AVC GOLD MODEL 1
45 144 2765 135 Front panel ass’y AVC BLACK MODEL 1
46 341 0049 001 Catcher 1
47 421 0750 007 Mini damper 1
58
