AVR-4802/AVC-A11SR
SAFETY PRECAUTIONS
The following check should be performed for the continued protection of the customer and service technician.
LEAKAGE CURRENT CHECK
Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis
resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the
power cord is less than 460 kohms, the unit is defective.
SPECIFICATIONS
Audio Section
Power amplifier:
Rated output: Stereo (2 ch driven)
(All properties shown are only for the 125 W + 125 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.05 % T.H.D.)
power amplifer stage.) 150 W + 150 W (6 Ω/ohms, 20 Hz ~ 20 kHz with 0.05 % T.H.D.)
Dynamic power: 170 W × 2 ch (8 Ω/ohms)
270 W × 2 ch (4 Ω/ohms)
350 W × 2 ch (2 Ω/ohms)
Output terminals: Front/Center: 6 ~ 16 Ω/ohms
Surround: A or B 6 ~ 16 Ω/ohms
A + B 8 ~ 16 Ω/ohms
Analog:
Input sensitivity/input impedance: 200 mV/47 kΩ/kohms
Frequency response: 10 Hz ~ 100 kHz: +0, −3 dB (DIRECT mode)
S/N: 105 dB (DIRECT mode)
Distortion: 0.005 % (20 Hz ~ 20 kHz) (DIRECT mode)
Rated output/maximum output: 1.2 V/8 V
Digital:
D/A output: Rated output 2 V (at 0 dB playback)
Total harmonic distortion 0.005 % (1 kHz, at 0 dB)
S/N ratio 110 dB
Dynamic range 108 dB
Digital input: Format Digital audio interface
Phono equalizer (PHONO input
REC OUT):
Input sensitivity: 2.5 mV
RIAA deviation: ±1 dB (20 Hz to 20 kHz)
Signal-to-noise ratio: 74 dB (A weighting, with 5 mV input)
Rated output/Maximum output: 150 mV/8V
Distortion factor: 0.03 % (1 kHz, 3 V)
Video Section
Standard video jacks
Input/output level and impedance: 1 Vp-p, 75 Ω/ohms
Frequency response: 5 Hz ~ 10 MHz +0, −3 dB
S-video jacks
Input/output level and impedance: Y (brightness) signal 1 Vp-p, 75 Ω/ohms
C (color) signal 0.286 Vp-p, 75 Ω/ohms
Frequency response: 5 Hz ~ 10 MHz +0, −3 dB
Color component video terminal:
Input/output level and impedance: Y (brightness) signal 1 Vp-p, 75 Ω/ohms
P
B/CB (blue) signal 0.7 Vp-p, 75 Ω/ohms
P
R/CR (red) signal 0.7 Vp-p, 75 Ω/ohms
Frequency response: DC ~ 50 MHz +0, −3 dB
Tuner Section
[FM] (note: µV at 75 Ω/ohms, 0 dBf = 1 × 10
-15
W) [AM]
Receiving range: 87.5 MHz ~ 107.9 MHz 520 kHz ~ 1710 kHz
Usable sensitivity: 1.0 µV (11.2 dBf) 18 µV
50 dB Quieting sensitivity: MONO 1.6 µV (15.3 dBf)
STEREO 23 µV (38.5 dBf)
Signal to Noise Ratio (IHF-A): MONO 77 dB 50 dB
STEREO 72 dB
Total Harmonic Distortion (at 1 kHz): MONO 0.15 %
STEREO 0.3 %
General
Power supply: AC 120 V, 60 Hz (U.S.A., Canada & Taiwan R.O.C. model)
AC 230 V, 50 Hz (Europe & Asia model)
AC 220 V, 50 Hz (China model)
Power consumption: 10.5 A (U.S.A., & Canada model)
Maximum external dimensions: 434 (W) × 179 (H) × 485 (D) mm (17-3/32″ × 7-3/64″ × 19-3/32″)
Mass: 20.5 kg (45 lbs 3.1 oz)
Remote Control Unit (RC-8000): AVR Model only
Batteries: LR6/AA Type (four batteries)
External dimensions: 96 (W) × 38 (H) × 168.5 (D) mm (3-25/32″ × 1-1/2″ × 6-41/64″)
Mass: 242 g (Approx. 8.5 oz) (not including batteries)
Remote Control Unit (RC-899): AVC Model only
Batteries: R6P/AA Type (three batteries)
External dimensions: 61 (W) × 230 (H) × 34 (D) mm (2-13/32″ × 9-1/16″ × 1-11/32″)
Mass: 150 g (Approx. 5.3 oz) (not including batteries)
* For purposes of improvement, specifications and design are subject to change without notice.
