Denon AVR-4306 Control Protocol

06.April.06
14/28
mServer/USB Extended Control
COMMAND PARAMETER
function example
SI AUXUSB Select INPUT source AUXNET and USB Start Playback SIAUXUSB<CR>
Z2 AUXUSB Select MULTI ZONE-2 source AUXNET and USB Start Playback Z2AUXUSB<CR>
Z3 AUXUSB Select MULTI ZONE-2 source AUXNET and USB Start Playback Z3AUXUSB<CR>
NS 90 “Cursor Up” Control NS90<CR>
91 “Cursor Down” Control NS91<CR>
92 “Cursor Left” Control NS92<CR>
93 “Cursor Right” Control NS93<CR>
94 “Enter (Play/Pause)” Control NS94<CR>
9A “Play” Control NS9A<CR>
9B “Pause” Control NS9B<CR>
9C “Stop” Control NS9C<CR>
9D “Skip Plus” Control NS9D<CR>
9E “Skip Minus” Control NS9E<CR>
9H “Repeat One” (USB Only) NS9H<CR>
9I “Repeat All” (USB Only) NS9I<CR>
9J “Repeat Off” (USB Only) NS9J<CR>
9K “Random On/Repeat ALL” (USB Only) NS9K<CR>
9L “Random Off” (USB Only) NS9L<CR>
NSA Request Onscreen Display Information List(mserver/USB) NSA<CR>
(ASCII CODE Character ) (Return NSA0-NSA8.
Refer to Page 25）
NSE Request Onscreen Display Information List(mserver/USB) NSE<CR>
(UTF-8 CODE Character ) (Return NSE0-NSE8.
Refer to Page 26）

Denon AVR-4306 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	130 W
HDMI in	3
Line-in	Yes
Composite video in	7
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	5
Headphone connectivity	3.5 mm
Speakers connectivity type	RCA
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	570 W
3D	-
Optical drive included	No
Product color	Silver
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES, Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	18500 g
