AVR-4308CI
PARTS LIST OF EXPLODED VIEW
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Ref. No. nsp Part No. Part Name Remarks Q'ty New
1 00D 1U- 3799 DIGITAL UNIT ASSY 1 *
2 - A.VIDEO UNIT ASSY 1 *
2-1 A.VIDEO UNIT
2-2 VIDEO CONNECT UNIT
2-3 FRONT IN UNIT
2-4 MIC UNIT
2-5 USB UNIT
2-6 DIGITAL IN UNIT
2-7 232C UNIT
2-8 BKT1 UNIT
2-9 BKT2 UNIT
3 - P.AMP UNIT ASSY 1 *
3-1 P.AMP UNIT
3-2 IPOD UNIT
3-3 AUDIO CONNECT UNIT
3-4 EX2 SP UNIT
3-5 REMOTE UNIT
3-6 LR CONNECT UNIT
4 - P.SUPPLY UNIT ASSY 1 *
4-1 PRIMARY UNIT
4-2 P.SUPPLY-1 UNIT
4-3 VOL_AMP UNIT
4-4 SIDE CONNECT UNIT
4-6 AMP CONNECT UNIT
4-8
5 - FRONT UNIT ASSY 1 *
5-1 P.SUPPLY-2 UNIT
5-2 FLD UNIT
5-3 TACT-1 UNIT
5-4 TACT-2 UNIT
5-5 FUNC UNIT
5-6 H/P CONNECT UNIT
5-7 VOL UNIT
5-8 VOL CONNECT UNIT
5-9 P.SW UNIT
5-10 FUNC CONNECT UNIT
5-11 H/P UNIT
5-21
6 - AUDIO/CPU UNIT ASSY 1 *
6-1 AUDIO UNIT
6-2 MAIN CPU UNIT
7 - DIGITAL POWER UNIT ASSY 1 *
8 - HD RADIO JOINT UNIT ASSY 1 *
11 nsp 00D 411 2106 102 MAIN CHASSIS 1 *
12 nsp 00D 411 2108 003 CENTER CHASSIS 1 *
13 nsp 00D 412 5363 000 BOTTOM PLATE 1 *
14 nsp 00D 104 0334 007 FOOT 4
15 nsp 00D 461 0385 001 RUBBER PAD 4
16 - RADIATOR 1 *
17 - CU PLATE 1 *
18 00D 278 0017 007 MN15N/MP15P 7 *
18-1 - MN15N TR201,203,205,207,209,211,213
18-2 - MP15P TR202,204,206,208,210,212,214
