133
AVR-4308CI
19 - PWB BRACKET 2 *
20 - RADIATOR BRACKET (L) 1 *
21 - RADIATOR BRACKET (R) 1 *
22 - PUSH RIVET Fix 1U-3803-21 2
23 - CARD SPACER (L=8) 2
24 - CARD SPACER(L=10) 2
25 - P.W.B.HOLDER (H=8) Fix CPU POWER UNIT 2
26 nsp 00D 105 1678 202 BACK PANEL 1 *
27 nsp 00D 409 0052 006 HOLDER (A) Fix LR CONNECT UNIT 1
28 00D 216 0124 002 AM FM TUNER(E3) 1
29 nsp 00D 004 0015 000 ANNTENA CABLE 1 *
30 00D 399 1099 004 WLAN MODULE(11CH) 1 *
31 nsp 00D 461 0957 044 RUBBER FOAM 1U-3804-2 2
32 00D 205 1116 006 TERMINAL ASS 1
! 33 00D 203 3996 008 AC INLET (2P) 1
★ 34
nsp 00D 203 2445 000 2P VA CORD AC INLET to CX021 1
35 - P.W.B.HOLDER (H=6) Fix SIDE CONNECT UNIT 1
36 - P.W.B.HOLDER (H=10) Fix MAIN CPU UNIT 1
37 - CARD SPACER (H=10) Fix MAIN CPU UNIT 1
★ 38
- WIRE CLAMPER 9
39 00D 216 0131 008 AO-4KR(HD RADIO/AVR) 1 *
40 00D 004 0014 001 F-TERMINAL ASSY 1
41 nsp 00D 449 0228 003 PCB HOLDER (WN-08F) 2
42 nsp 00D 461 1291 000 SPACER 1
43 nsp 00D 412 5347 107 FIX BRACKET 1
! 44 00D 233 6577 001 MAIN TRANS(43CIE3) 1 *
47 nsp 00D 513 3333 005 LABEL (TRANS) 1
48 nsp 00D 461 0573 033 RUBBER SHEET 1
49 nsp 00D GEN 8387 TOP COVER SUB ASSY 00D1020702109 : TOP COVER 1 *
★ 50
nsp 00D GEN 8389 LICENSE SUB ASSY 1 *
★ 51
- SERIAL NO. SHEET 1
52 nsp 00D 146 2487 008 SCREW COVER 1 *
53 - PUSH RIVET 2
★ 54
nsp 00D GEN 8383 FUSE CAUTION LABEL 1 *
55 - SHIELD BRACKET(HD) 1 *
60 00D 146 2486 106 INNER PANEL 1 *
61 00D 143 1281 002 DOOR SHEET 1 *
62 nsp 00D 461 1182 012 RUBBER SHEET Door close 2
63 nsp 00D 461 1182 009 RUBBER SHEET 20X10X1T / Door open 2
64 00D 143 1282 001 WINDOW 1 *
65 00D 113 1996 202 CURSOR KNOB 1
66 00D 113 1995 041 ENTER KNOB 1 *
67 nsp 00D 143 1255 009 LENS (POWER) 1
68 00D 113 1992 109 P.KNOB ASSY(SUB) 1
69 00D 113 1994 107 P.KNOB ASSY(MAIN) 1
70 - USB BRACKET 1 *
71 00D 421 0763 010 GEAR DAMPER 058E-L 1
72 nsp 00D 412 5083 102 DOOR STOPPER 1
73 - BKT2 UNIT
Cut PWB Board:Part No.2-9(1U-3800-9)
1
74 - BKT1 UNIT
Cut PWB Board:Part No.2-8(1U-3800-8)
1
75 - D/S PLATE
Cut INN.PANEL:Part No.60
1
76 nsp 00D 411 2107 101 FRONT CHASSIS 1 *
77 00D 144 3010 203 FRONT PANEL 1 *
78 nsp 00D 135 0074 002 AL24 BADGE 1 *
79 nsp 00D 131 0158 049 DENON BADGE 1 *
80 nsp 00D 143 0952 002 LENS 3
81 00D 144 3021 001 DOOR ASSY 1 *
82 00D 401 0195 202 HINGE (L) 1
83 00D 401 0196 201 HINGE (R) 1
Ref. No. nsp Part No. Part Name Remarks Q'ty New
