THX Ultra Certified 2-channel Power Amplifier
POA-5200
The POA-5200 dual monaural power amplifier provides
superb stereo reproduction, and is an ideal choice for adding
additional amplifier channels to a multi-channel system. For
example, when combined with Denon’s AVR-4800 THX
Surround EX A/V receiver, the POA-5200 can be used as the
stereo front channels (left and right) amplifier, or the surround
center back channels amplifier.
The POA-5200 meets Lucasfilm’s stringent THX Ultra certifi-
cation requirements, and provides 120 watts of power per
channel, RMS into 8 ohms, and 200 watts of power per chan-
nel, RMS into 4 ohms.
■
THX Ultra Certified
Lucasfilm’s stringent THX Ultra certification for power amplifiers includes
dozens of tests and specification requirements, all to ensure accurate repro-
duction of motion picture soundtracks and musical performances. All aspects
of power amplifier performance are thoroughly verified, to ensure inaudible
noise, wide dynamic range, extended frequency response with accurate
spectral response, and the ability to drive any modern loudspeaker regardless
of impedance or efficiency.
■
Dual Monaural Configuration
Unlike conventional stereo power amplifiers, which rely upon a shared
power supply for both amp channels, the POA-5200 features Denon’s perfect
Dual Monaural Configuration, with a separate high current power transformer
and DC storage supply section for each amplifier channel. This provides the
widest dynamic range, along with tremendous reserve capacity, compared to
conventional stereo amplifiers.
■
Stabilized DC Characteristics
The use of a FET for difference input of one package type with superior
direct current (DC) temperature characteristics and the ability to fine-adjust
each channel individually have realized a high precision of 1 mV or less
(standard value) in the output DC voltage of the POA-5200.This high-pre-
cision voltage is approximately one tenth that of conventional models and is
the main reason these models are able to reproduce low-level signals with
such exceptional fidelity.
■
A-B Speaker switching for each channel
■
Strictly Selected Parts for High Sound Quality
A large number of high-performance parts, such as the electrolytic capaci-
tor customized for high sound quality, OFC wiring material, film capacitor and
resistors, have all been subject to stringent listening tests during their selection
process to ensure unfettered, high-grade sound reproduction.
■
Remote Power ON/OFF
Rear panel mounted remote power on/off terminals are provided, for
connection to Denon components such as the AVR-4800, for one-button
power turn-on and turn-off convenience. This allows the power amplifier to
be mounted in an out-of-the-way location, thereby saving valuable shelf
space for more importantly accessible source components, for example.
Specifications
Rated output . . . . . . . . . . . . 120 W x 2 (8 ohms, 20 Hz - 20 kHz,THD 0.02 %)
200 W x 2 (4 ohms, 1 kHz, THD 0.5%)
Total harmonic Distortion . . . 0.008 % (-3 dB at rated output, 8 ohms, 20 Hz - 20 kHz)
Inter modulation Distortion . . 0.002 % (60 Hz/7 kHz : 4/1 at rated output, 8 ohms)
Frequency response . . . . . . 1 Hz - 100 kHz +0, -3 dB (at 1 W)
Input sensitivity . . . . . . . . . . 1.1 V
Input impedance . . . . . . . . . 47 kohms
Output impedance . . . . . . . . 0.1 ohms (1 kHz)
Signal-to-noise ratio . . . . . . . 110 dB (IHF, A-weighting)
Speaker . . . . . . . . . . . . . . . . A or B 4 ohms - 16 ohms
A + B 8 ohms - 16 ohms
Power supply . . . . . . . . . . . AC 120V, 60 Hz
Power consumption . . . . . . . 4.7 A
Dimensions . . . . . . . . . . . . . 434 (W) x 135 (H) x 353 (D) mm
17.1(W) x 5.3(H) x 13.9(D)
Weight . . . . . . . . . . . . . . . . 12.3 kg, 27.1 lbs
DENON ELECTRONICS
DIVISION OF DENON CORPORATION (U.S.A.)
222 NEW ROAD, PARSIPPANY, NEW JERSEY 07054, U.S.A. TEL:973-396-0810
www.del.denon.com
DENON CANADA,INC.
17 DENISON STREET, MARKHAM ONTARIO, CANADA L3R 1B5 TEL:905-475-4085
LABRADOR, S. A. DE C. V.
ZAMORA NO. 154, COL. CONDESA MEXICO D. F. C. P. 06140 TEL : 286-55-09/79
NIPPON COLUMBIA CO., LTD.
14-14,AKASAKA 4-CHOME, MINATO-KU, TOKYO 107-8011, JAPAN www.denon.co.jp
12120200 No.2 A Printed in Japan
*Design and specifications are subject to change without notice.
*THX is a registered trademark of Lucasfilm Ltd.
*© Lucasfilm Ltd. & TM. All Rights Reserved. Surround EX is a jointly developed technology of THX and Dolby Labs, Inc., and is a trademark of
Dolby. Used under authorization.
*”Dolby”, “Dolby Digital”, “Pro Logic”, and the double-D device are registered trademarks of Dolby Laboratories Licensing Corporation.
*DTS is registered trademarks of DTS Technology.
