Denon AVR-487 Service Manual

52
AVR-1707/1507/687/587/487
CP702 nsp 00D 963 0087 504 CN.WAFER 19P L101100041910S
CP703 nsp 00D 963 0097 507 CN.WAFER 15P L101100041510S
CP704 00D 963 0256 908 CN.WAFER 10P L101100041010S
CP801 nsp 00D 963 0087 601 CN.WAFER 18P L101100041810S
CP802 nsp 00D 963 0087 504 CN.WAFER 19P L101100041910S
CP803 nsp 00D 963 0087 407 CN.WAFER 16P L101100041610S
G301 00D 963 0257 509 RING,TER WIRE 80MM/1P 8410800010100F
GND201 - TERMINAL EARTH 3790040886000S
L301 nsp 00D 960 0128 008 COIL,INDUCTOR 100UH D330101001020S
L302 nsp 00D 960 0010 307 COIL,INDUCTOR 10UH D330100700520S
RMC301 00D 963 0217 808 MODULE,REMOCON
NJL34H380A
E940343800010P
SW301C 00D 963 0200 103 SW,TACT SKHV10920A G180000270010S
SW302A 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW302B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW302C 00D 963 0200 103 SW,TACT SKHV10920A G180000270010S
SW303A 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW303B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW303C 00D 963 0200 103 SW,TACT SKHV10920A G180000270010S
SW304A 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW304B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW304C 00D 963 0200 103 SW,TACT SKHV10920A G180000270010S
SW305A 00D 963 0200 103 SW,TACT SKHV10920A G180000270010S
SW305B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW305C 00D 963 0200 103 SW,TACT SKHV10920A G180000270010S
SW306A 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW306B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW306C 00D 963 0200 103 SW,TACT SKHV10920A G180000270010S
SW307B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW307C 00D 963 0200 103 SW,TACT SKHV10920A G180000270010S
SW308B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW308C 00D 963 0200 103 SW,TACT SKHV10920A G180000270010S
SW309B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW309C 00D 963 0200 103 SW,TACT SKHV10920A G180000270010S
!
SW931 00D 963 0145 802 SW,PUSH SDDL-005-S(C-UL) G000122006060F
TP301 nsp 00D 963 0060 709 CN.WAFER 8P L101220080000S
TP601 00D 960 0123 605 CN.WAFER 13P L101530141310S
VEC301,302 00D 963 0095 208 SW,ENCODER EC16B24SA G121162400040S
X201 00D 963 0217 701 RESONATOR,CERAMIC
ZTT12.00MT
E830120000060P
X202 00D 963 0217 604 CRYSTAL 4.332MHZ, 1707E2 E800433200100
- HEAT SINK 2120043538050S
nsp 00D 963 0018 007 SCREW, 3*8 B-TYPE ZNY/BH B020030081B10S
nsp 00D 960 0184 408 HOLDER FLT 4320200026000S
00D 963 0146 403 TER,RCA 3PIN G606308HG110YS
Ref. No. nsp Part No. Part Name Remarks Q'ty New
