Denon AVR-5800 - Page 37

37
[3] Outputting a program source to an amplifier, etc., in a different room (M-ZONE 1 mode)
1
Press the M-ZONE 1 button.
M-ZONE 1
2
Select the source you want to output
appears on the set’s display.
FUNCTION
(Main unit)
3
Start playing the source to be output.
• For operating instructions, refer to the manuals of the
respective components.
(Main unit)
[4] Outputting a program source to an amplifier, etc., in a different room (M-ZONE 2)
1
Press the REC/M-ZONE 2 button until
“M-ZONE 2 SOURCE” appears on the
set’s display.
REC /
M-ZONE 2
11, 2 2
(Main unit)
VCR -1 -2 V.AUX MD / TAPE -1 -2
PHONO CD TUNER AUX DVD / VDP TV / DBS
2
Display
2
Select the source you want to record
appears on the set’s display.
• The MULTI indicator lights.
• The indicator for the selected
program source light.
• When the AVR-5800 is in the REC
OUT mode, the source cannot be
output using the M-ZONE 2 buttons
on the remote control unit.
FUNCTION
(Main unit)
3
Start playing the source to be output.
• For operating instructions, refer to the manuals of the
respective components.
NOTES:
• The signals of the source selected in the M-ZONE-2 mode are
also output from the TAPE and VCR recording output terminals.
• Digital signals are not output from the MULTI ZONE 1 audio
output jacks.
When “M-ZONE 2” is selected for the system setup’s multi-zone
setting, the source selected here is output from the M-ZONE 2
speaker terminals.
The volume can be adjusted and the input source can be selected
using the VOLUME UP and VOLUME DOWN buttons on the remote
control unit’s “M-ZONE 2” page.
