Denon AVR-5803 Service Manual

59
AVR-5803/AVC-A1SR
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
TR507 274 0163 904 Transistor 2SD601A
TR508 272 0125 904 Transistor 2SB709A
TR509,510 269 0082 902 Transistor DTC114EK
TR601 269 0083 901 Transistor DTA114EK
TR602 269 0082 902 Transistor DTC114EK
TR701 269 0082 902 Transistor DTC114EK
TR702 269 0083 901 Transistor DTA114EK
TR703 269 0082 902 Transistor DTC114EK
TR704 269 0083 901 Transistor DTA114EK
TR705-710 269 0082 902 Transistor DTC114EK
TR711 269 0083 901 Transistor DTA114EK
TR712 273 0384 900 Transistor 2SC2412K (S)
TR713 269 0054 901 Transistor DTC144EK
TR714 271 0238 908 Transistor 2SA1037K (S/R)
TR715-718 273 0384 900 Transistor 2SC2412K (S)
TR719 271 0238 908 Transistor 2SA1037K (S/R)
TR720,721 273 0384 900 Transistor 2SC2412K (S)
TR722 269 0054 901 Transistor DTC144EK
TR723,724 269 0082 902 Transistor DTC114EK
TR725 272 0161 900 Transister 2SB1412TL (PQR)
TR726,727 269 0082 902 Transistor DTC114EK
TR728 274 0163 904 Transistor 2SD601A
TR729 269 0054 901 Transistor DTC144EK
TR730 269 0082 902 Transistor DTC114EK
TR731 272 0161 900 Transister 2SB1412TL (PQR)
TR732,733 269 0082 902 Transistor DTC114EK
TR734,735 269 0054 901 Transistor DTC144EK for EU,EC
TR736-738 269 0082 902 Transistor DTC114EK
TR739 269 0083 901 Transistor DTA114EK
TR740,741 269 0054 901 Transistor DTC144EK for EU,EC
TR751,752 272 0161 900 Transister 2SB1412TL (PQR)
TR753,754 269 0082 902 Transistor DTC114EK
TR800 269 0048 904 Transistor DTC143EK
TR801 272 0161 900 Transister 2SB1412TL (PQR)
TR802 269 0082 902 Transistor DTC114EK
TR803 269 0083 901 Transistor DTA114EK
TR804,805 269 0082 902 Transistor DTC114EK
TR806 272 0161 900 Transister 2SB1412TL (PQR)
TR807-809 269 0082 902 Transistor DTC114EK
TR810 269 0054 901 Transistor DTC144EK
D152-155 276 0560 901 Diode DAN202K
D157,158 276 0559 909 Diode DAP202K
D160 276 0559 909 Diode DAP202K
D501-505 276 0738 908 Diode KDS226
D507 276 0739 907 Diode KDS181
D508 276 0663 905 Diode KV1851
D701,702 276 0559 909 Diode DAP202K
D703,704 276 0751 901 Diode 1SR154-400
D707 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
D802 276 0559 909 Diode DAP202K
ZD701 276 0693 946 Zener diode UDZ3.0B
RESISTORS GROUP
R101-104 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R105 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
R106 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R107 247 0031 937 Carbon chip 16kohm 1/10W RM73B--163J (AD)
R109,110 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R111-118 247 0029 949 Carbon chip 2.7kohm 1/10W RM73B--272J (AD)
R119,120 247 0030 925 Carbon chip 5.6kohm 1/10W RM73B--562J (AD)
R121,122 247 0030 912 Carbon chip 5.2kohm 1/10W RM73B--512J (AD)
R123,124 247 0030 925 Carbon chip 5.6kohm 1/10W RM73B--562J (AD)
R125,126 247 0030 912 Carbon chip 5.2kohm 1/10W RM73B--512J (AD)
R127-134 247 0029 936 Carbon chip 2.4kohm 1/10W RM73B--242J (AD)
R135-138 247 0029 978 Carbon chip 3.6kohm 1/10W RM73B--362J (AD)
R139-142 247 2009 909 Carbon chip 4.7kohm 1/16W RM73B--472J
R143,144 247 2006 960 Carbon chip 470ohm 1/16W RM73B--471J
R145,146 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R149,150 247 0028 953 Carbon chip 1.1kohm 1/10W RM73B--112J (AD)
R151,152 247 0028 924 Carbon chip 820ohm 1/10W RM73B--821J (AD)
R155,156 247 0028 940 Carbon chip 1kohm 1/10W RM73B--102J (AD)
R157-160 247 0027 996 Carbon chip 620ohm 1/10W RM73B--621J (AD)
R161,162 247 2012 925 Carbon chip 100kohm 1/16W RM73B--104J
R163-166 247 0027 954 Carbon chip 430ohm 1/10W RM73B--431J (AD)
R167-170 247 2012 967 Carbon chip 150kohm 1/16W RM73B--154J
R171,172 247 2010 943 Carbon chip 18kohm 1/16W RM73B--183J
R173,174 247 0027 925 Carbon chip 330ohm 1/10W RM73B--331J (AD)
R175,176 247 2008 926 Carbon chip 2.2kohm 1/16W RM73B--222J
R181 247 2011 942 Carbon chip 47kohm 1/16W RM73B--473J
R182-185 247 2009 909 Carbon chip 4.7kohm 1/16W RM73B--472J
R186-189 247 2010 969 Carbon chip 22kohm 1/16W RM73B--223J
R191 247 2007 943 Carbon chip 1kohm 1/16W RM73B--102J
R192 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
R193 247 2007 943 Carbon chip 1kohm 1/16W RM73B--102J
R194 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
R195 247 2007 943 Carbon chip 1kohm 1/16W RM73B--102J
R196 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
R197 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R201-204 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R206 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R207 247 0031 937 Carbon chip 16kohm 1/10W RM73B--163J (AD)
R209,210 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R211-218 247 0029 949 Carbon chip 2.7kohm 1/10W RM73B--272J (AD)
R219,220 247 0030 925 Carbon chip 5.6kohm 1/10W RM73B--562J (AD)
R221,222 247 0030 912 Carbon chip 5.2kohm 1/10W RM73B--512J (AD)
