Denon AVR-5803 - 1 U-3296 G;3296 H POWER AMP P.W.B. UNIT ASSY

73
AVR-5803/AVC-A1SR
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
1U-3296G/3296H POWER AMP P.W.B. UNIT ASS'Y
SEMICONDUCTORS GROUP
TR101,102 273 0459 903 Transistor KTC2874B
TR103-106 273 0235 923 Transistor 2SC1841 (E/F)
TR107-110 271 0304 007 Transistor 2SA1546 (M/L)
TR111,112 273 0453 006 Transistor 2SC4001 (M/L)
TR113,114 273 0445 001 Transistor 2SC4495
TR115,116 273 0235 923 Transistor 2SC1841 (E/F)
TR123-126 275 0055 015 FET 2SK184C (GR)/(BL)
TR201,202 273 0459 903 Transistor KTC2874B
TR203-206 273 0235 923 Transistor 2SC1841 (E/F)
TR207-210 271 0304 007 Transistor 2SA1546 (M/L)
TR211,212 273 0453 006 Transistor 2SC4001 (M/L)
TR213,214 273 0445 001 Transistor 2SC4495
TR215,216 273 0235 923 Transistor 2SC1841 (E/F)
TR223-226 275 0055 015 FET 2SK184C (GR)/(BL)
TR301,302 273 0459 903 Transistor KTC2874B
TR303-306 273 0235 923 Transistor 2SC1841 (E/F)
TR307-310 271 0304 007 Transistor 2SA1546 (M/L)
TR311,312 273 0453 006 Transistor 2SC4001 (M/L)
TR313,314 273 0445 001 Transistor 2SC4495
TR315,316 273 0235 923 Transistor 2SC1841 (E/F)
TR323-326 275 0055 015 FET 2SK184C (GR)/(BL)
TR402 273 0459 903 Transistor KTC2874B
TR404 273 0235 923 Transistor 2SC1841 (E/F)
TR406 273 0235 923 Transistor 2SC1841 (E/F)
TR408 271 0304 007 Transistor 2SA1546 (M/L)
TR410 271 0304 007 Transistor 2SA1546 (M/L)
TR412 273 0453 006 Transistor 2SC4001 (M/L)
TR414 273 0445 001 Transistor 2SC4495
TR416 273 0235 923 Transistor 2SC1841 (E/F)
TR424 275 0055 015 FET 2SK184C (GR)/(BL)
TR426 275 0055 015 FET 2SK184C (GR)/(BL)
TR503-510 273 0388 906 Transistor 2SC1740S (E)
TR512,513 273 0388 906 Transistor 2SC1740S (E) for EU,EC
TR514 273 0388 906 Transistor 2SC1740S (E)
TR517,518 271 0131 924 Transistor 2SA988 (E/F)
TR519,520 273 0388 906 Transistor 2SC1740S (E)
D101-104 276 0432 903 Diode 1SS270A
D105,106 276 0455 906 Zener diode HZS4A-1
D107,108 276 0456 918 Zener diode HZS4B-2
D109-116 276 0432 903 Diode 1SS270A
D201-204 276 0432 903 Diode 1SS270A
D205,206 276 0455 906 Zener diode HZS4A-1
D207,208 276 0456 918 Zener diode HZS4B-2
D209-216 276 0432 903 Diode 1SS270A
D301-304 276 0432 903 Diode 1SS270A
D305,306 276 0455 906 Zener diode HZS4A-1
D307,308 276 0456 918 Zener diode HZS4B-2
D309-316 276 0432 903 Diode 1SS270A
D402 276 0432 903 Diode 1SS270A
D404 276 0432 903 Diode 1SS270A
D406 276 0455 906 Zener diode HZS4A-1
D408 276 0456 918 Zener diode HZS4B-2
D410 276 0432 903 Diode 1SS270A
D412 276 0432 903 Diode 1SS270A
D414 276 0432 903 Diode 1SS270A
D416 276 0432 903 Diode 1SS270A
D501-508 276 0432 903 Diode 1SS270A
D510,511 276 0432 903 Diode 1SS270A for EU,EC
D512 276 0432 903 Diode 1SS270A
D552 276 0704 903 Diode 1SR35-400A
ZD552 276 0643 970 Zener diode MTZJ4.7A
PT501,502 279 0034 067
Posistor PTH9M04BB222TS2F333
PT503,504 279 0034 070 Posistor PTH9M04BE222TS2F333
RESISTORS GROUP
R111,112 241 2378 962 Carbon film 330ohm 1/4W (NB) RD14B2E331JNBS
R119,120 241 2378 962 Carbon film 330ohm 1/4W (NB) RD14B2E331JNBS
R123,124 241 2315 983 Carbon film 330ohm 1/4W (FR) RD14B2E331GFRS
R125,126 244 2671 914 Metal oxide 15kohm 2W (NB) RS14B3D153JNBS (S)
R127,128 241 2371 930 Carbon film 160ohm 1/4W (FR) RD14B2E161GFRS
R129,130 241 2315 983 Carbon film 330ohm 1/4W (FR) RD14B2E331GFRS
R137-140 241 2387 940 Carbon film 4.7ohm 1/4W (NB) RD14B2E4R7JNBS
R141-148 244 2671 943 Metal oxide 0.22ohm 2W (NB) RS14B3DR22JNBS (S)
R165-168 244 2671 930 Metal oxide 22ohm 2W (NB) RS14B3D220JNBS (S)
R171,172 241 2380 918 Carbon film 1.3kohm 1/4W (NB) RD14B2E132JNBS
R173,174 241 2377 921 Carbon film 82ohm 1/4W (NB) RD14B2E820JNBS
R189,190 241 2371 930 Carbon film 160ohm 1/4W (FR) RD14B2E161GFRS
R211,212 241 2378 962 Carbon film 330ohm 1/4W (NB) RD14B2E331JNBS
R219,220 241 2378 962 Carbon film 330ohm 1/4W (NB) RD14B2E331JNBS
R223,224 241 2315 983 Carbon film 330ohm 1/4W (FR) RD14B2E331GFRS
R225,226 244 2671 914 Metal oxide 15kohm 2W (NB) RS14B3D153JNBS (S)
R227,228 241 2371 930 Carbon film 160ohm 1/4W (FR) RD14B2E161GFRS
R229,230 241 2315 983 Carbon film 330ohm 1/4W (FR) RD14B2E331GFRS
R237-240 241 2387 940 Carbon film 4.7ohm 1/4W (NB) RD14B2E4R7JNBS
R241-248 244 2671 943 Metal oxide 0.22ohm 2W (NB) RS14B3DR22JNBS (S)
R265-268 244 2671 930 Metal oxide 22ohm 2W (NB) RS14B3D220JNBS (S)
R271,272 241 2380 918 Carbon film 1.3kohm 1/4W (NB) RD14B2E132JNBS
R273,274 241 2377 921 Carbon film 82ohm 1/4W (NB) RD14B2E820JNBS
R289,290 241 2371 930 Carbon film 160ohm 1/4W (FR) RD14B2E161GFRS
R311,312 241 2378 962 Carbon film 330ohm 1/4W (NB) RD14B2E331JNBS
