Denon AVR-5803 Service Manual

74
AVR-5803/AVC-A1SR
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
C125-128 254 4527 995 Electrolytic 22uF/100V CE04W2A220M (SMG/RE3)
C129-131 254 4313 976 Electrolytic 2.2uF/50V CE04W1H2R2M (ASF)
C133-136 254 4313 976 Electrolytic 2.2uF/50V CE04W1H2R2M (ASF)
C139,140 255 4235 976 Polypropylene film 0.015uF/100V CQ93P2A153J (NH)
C203,204 255 1273 902 Mylar film 100pF/50V CQ93M1H101K (B)
C207,208 255 1264 940 Mylar film 2200pF/50V CQ93M1H222J (B)
C209,210 255 4242 969
Polypropylene film 27pF/100V CQ93P2A270J (NH)
C211,212 254 4313 976 Electrolytic 2.2uF/50V CE04W1H2R2M (ASF)
C213,214 253 4484 909 Ceramic 39pF/500V CC45SL2H390J
C215,216 254 4527 995 Electrolytic 22uF/100V
CE04W2A220M (SMG/RE3)
C218,219 255 1265 936 Mylar film 0.01uF/50V CQ93M1H103J (B)
C222,223 255 4235 976
Polypropylene film 0.015uF/100V CQ93P2A153J (NH)
C225-228 254 4527 995 Electrolytic 22uF/100V
CE04W2A220M (SMG/RE3)
C239,240 255 4235 976 Polypropylene film 0.015uF/100V CQ93P2A153J (NH)
C303,304 255 1273 902 Mylar film 100pF/50V CQ93M1H101K (B)
C307,308 255 1264 940 Mylar film 2200pF/50V CQ93M1H222J (B)
C309,310 255 4242 969 Polypropylene film 27pF/100V CQ93P2A270J (NH)
C311,312 254 4313 976 Electrolytic 2.2uF/50V CE04W1H2R2M (ASF)
C313,314 253 4484 909 Ceramic 39pF/500V CC45SL2H390J
C315,316 254 4527 995 Electrolytic 22uF/100V CE04W2A220M (SMG/RE3)
C319,320 255 1265 936 Mylar film 0.01uF/50V CQ93M1H103J (B)
C323,324 255 4235 976 Polypropylene film 0.015uF/100V CQ93P2A153J (NH)
C325-328 254 4527 995 Electrolytic 22uF/100V CE04W2A220M (SMG/RE3)
C339,340 255 4235 976 Polypropylene film 0.015uF/100V CQ93P2A153J (NH)
C404 255 1273 902 Mylar film 100pF/50V CQ93M1H101K (B)
C408 255 1264 940 Mylar film 2200pF/50V CQ93M1H222J (B)
C410 255 4242 969 Polypropylene film 27pF/100V CQ93P2A270J (NH)
C412 254 4313 976 Electrolytic 2.2uF/50V CE04W1H2R2M (ASF)
C414 253 4484 909 Ceramic 39pF/500V CC45SL2H390J
C416 254 4527 995 Electrolytic 22uF/100V CE04W2A220M (SMG/RE3)
C420 255 1265 936 Mylar film 0.01uF/50V CQ93M1H103J (B)
C424 255 4235 976 Polypropylene film 0.015uF/100V CQ93P2A153J (NH)
C426 254 4527 995 Electrolytic 22uF/100V CE04W2A220M (SMG/RE3)
C428 254 4527 995 Electrolytic 22uF/100V CE04W2A220M (SMG/RE3)
C440 255 4235 976 Polypropylene film 0.015uF/100V CQ93P2A153J (NH)
C505-512 254 4524 985 Electrolytic 10uF/50V CE04W1H100M (SMG/RE3)
C514,515 254 4524 985 Electrolytic 10uF/50V CE04W1H100M (SMG/RE3)
for EU,EC
C516 254 4524 985 Electrolytic 10uF/50V CE04W1H100M (SMG/RE3)
C519,520 255 1265 936 Mylar film 0.01uF/50V CQ93M1H103J (B)
C521,522 254 4533 947 Electrolytic 330uF/6.3V CE04W0J331M (SMG/RE3)
C552 254 4524 985 Electrolytic 10uF/50V CE04W1H100M (SMG/RE3)
C553-556 254 4524 943 Electrolytic 1uF/50V CE04W1H010M (SMG/RE3)
R319,320 241 2378 962 Carbon film 330ohm 1/4W (NB) RD14B2E331JNBS
R323,324 241 2315 983 Carbon film 330ohm 1/4W (FR) RD14B2E331GFRS
R325,326 244 2671 914 Metal oxide 15kohm 2W (NB) RS14B3D153JNBS (S)
R327,328 241 2371 930 Carbon film 160ohm 1/4W (FR) RD14B2E161GFRS
R329,330 241 2315 983 Carbon film 330ohm 1/4W (FR) RD14B2E331GFRS
R337-340 241 2387 940 Carbon film 4.7ohm 1/4W (NB) RD14B2E4R7JNBS
R341-348 244 2671 943 Metal oxide 0.22ohm 2W (NB) RS14B3DR22JNBS (S)
R365-368 244 2671 930 Metal oxide 22ohm 2W (NB) RS14B3D220JNBS (S)
R371,372 241 2380 918
Carbon film 1.3kohm 1/4W (NB) RD14B2E132JNBS
R373,374 241 2377 921 Carbon film 82ohm 1/4W (NB) RD14B2E820JNBS
R389,390 241 2371 930 Carbon film 160ohm 1/4W (FR) RD14B2E161GFRS
R412 241 2378 962
Carbon film 330ohm 1/4W (NB) RD14B2E331JNBS
R420 241 2378 962
Carbon film 330ohm 1/4W (NB) RD14B2E331JNBS
R424 241 2315 983 Carbon film 330ohm 1/4W (FR) RD14B2E331GFRS
R426 244 2671 914 Metal oxide 15kohm 2W (NB) RS14B3D153JNBS (S)
R428 241 2371 930 Carbon film 160ohm 1/4W (FR) RD14B2E161GFRS
R430 241 2315 983 Carbon film 330ohm 1/4W (FR) RD14B2E331GFRS
R438 241 2387 940 Carbon film 4.7ohm 1/4W (NB) RD14B2E4R7JNBS
R440 241 2387 940 Carbon film 4.7ohm 1/4W (NB) RD14B2E4R7JNBS
R442 244 2671 943 Metal oxide 0.22ohm 2W (NB) RS14B3DR22JNBS (S)
R444 244 2671 943 Metal oxide 0.22ohm 2W (NB) RS14B3DR22JNBS (S)
R446 244 2671 943 Metal oxide 0.22ohm 2W (NB) RS14B3DR22JNBS (S)
R448 244 2671 943 Metal oxide 0.22ohm 2W (NB) RS14B3DR22JNBS (S)
R466 244 2671 930 Metal oxide 22ohm 2W (NB) RS14B3D220JNBS (S)
R468 244 2671 930 Metal oxide 22ohm 2W (NB) RS14B3D220JNBS (S)
R472 241 2380 918 Carbon film 1.3kohm 1/4W (NB) RD14B2E132JNBS
R474 241 2377 921 Carbon film 82ohm 1/4W (NB) RD14B2E820JNBS
R490 241 2371 930 Carbon film 160ohm 1/4W (FR) RD14B2E161GFRS
R552 244 2051 974 Metal oxide 1kohm 1W (NB) RS14B3A102JNBS (S)
R554 244 2051 974 Metal oxide 1kohm 1W (NB) RS14B3A102JNBS (S)
R556 244 2051 974 Metal oxide 1kohm 1W (NB) RS14B3A102JNBS (S)
R558 244 2051 974 Metal oxide 1kohm 1W (NB) RS14B3A102JNBS (S)
VR131,132 211 6129 909 Semi fixed resistor 4.7kohm K06QB472
VR231,232 211 6129 909 Semi fixed resistor 4.7kohm K06QB472
VR331,332 211 6129 909 Semi fixed resistor 4.7kohm K06QB472
VR432 211 6129 909 Semi fixed resistor 4.7kohm K06QB472
CAPACITORS GROUP
C103,104 255 1273 902 Mylar film 100pF/50V CQ93M1H101K (B)
C107,108 255 1264 940 Mylar film 2200pF/50V CQ93M1H222J (B)
C109,110 255 4242 969 Polypropylene film 27pF/100V CQ93P2A270J (NH)
C111,112 254 4313 976 Electrolytic 2.2uF/50V CE04W1H2R2M (ASF)
C113,114 253 4484 909 Ceramic 39pF/500V CC45SL2H390J
C115,116 254 4527 995 Electrolytic 22uF/100V CE04W2A220M (SMG/RE3)
C119,120 255 1265 936 Mylar film 0.01uF/50V CQ93M1H103J (B)
C123,124 255 4235 976 Polypropylene film 0.015uF/100V CQ93P2A153J (NH)
