58
AVR-5803/AVC-A1SR
PARTS LIST OF P.W.B. UNIT ASS'Y
1U-3425/3425A DIGITAL P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
SEMICONDUCTORS GROUP
IC103 262 3072 905 IC PCM1738-1
IC104,105 263 1074 908 IC OP275GSR
IC106,107 263 0898 907 IC NJM5532MD
IC108,109 263 0896 909 IC NJM2068MD
IC110 262 2517 908 IC SN74LV08APW
IC111 262 2519 906 IC SN74LV00APW
IC203 262 3072 905 IC PCM1738-1
IC204,205 263 1074 908 IC OP275GSR
IC206,207 263 0898 907 IC NJM5532MD
IC208,209 263 0896 909 IC NJM2068MD
IC303 262 3072 905 IC PCM1738-1
IC304,305 263 1074 908 IC OP275GSR
IC306,307 263 0898 907 IC NJM5532MD
IC308,309 263 0896 909 IC NJM2068MD
IC403 262 3072 905 IC PCM1738-1
IC404,405 263 1074 908 IC OP275GSR
IC406,407 263 0898 907 IC NJM5532MD
IC408,409 263 0896 909 IC NJM2068MD
IC501-506 262 3065 006
Optical digital input (TORX141)
IC507,508 262 3064 007
Optical digital output (TOTX141)
IC510 262 2375 904 IC TC4094BF
IC511-514 262 3077 900 IC TC74VHCU04FT
IC515 262 2375 904 IC TC4094BF
IC516-519 262 2944 908 IC SN74HC151APW
IC520 262 2945 907 IC SN74HC153APW
IC523 262 3106 907 IC SN65LVDS32PW
IC524 262 3125 904 IC SN65LVDS179DGK
IC525 263 0687 901 IC BA4560F
IC526 263 1082 903 IC TK15420MTL
IC527 262 2372 004 IC PM4007A
IC528 262 2852 906 IC W24257S-70LL
IC600 262 3066 005 IC LC89057W
IC610 262 3067 907 IC SN65LVDS050D
IC611 262 3068 003 IC EPM3128ATC144-10
IC613,614 262 2959 906 IC SN74LV244APW
IC625 262 3066 005 IC LC89057W
IC650 262 3066 005 IC LC89057W
IC675 262 3066 005 IC LC89057W
IC677 262 3062 902 IC FCX0-03 (24.576MHz)
IC701 262 3073 001 IC M30620FCMGP
IC702-705 262 2785 905 IC SN74LV125APW
IC706 262 2813 903 IC SN74AHCT08PW
IC707 262 2519 906 IC SN74LV00APW
IC708,709 262 2375 904 IC TC4094BF
IC710 262 2517 908 IC SN74LV08APW
IC711 262 2813 903 IC SN74AHCT08PW
IC712 262 3075 009 IC MX29F400TTC-90
IC713 262 3074 000 IC M30802S
IC715,716 263 1079 903 IC BA033FP
IC717,718 263 1164 009 IC PQ018EF01SZ
IC721 262 2375 904 IC TC4094BF
IC723 263 1162 001 IC KIA78R12PI
IC801 263 0896 909 IC NJM2068MD
IC802 262 2729 903 IC SN74LV02APW
IC803-805 263 0934 900 IC BA4510F
IC806 262 3069 905 IC PCM1804
IC820 263 0615 902 IC BA15218F
IC851 263 0896 909 IC NJM2068MD
IC853-855 263 0934 900 IC BA4510F
IC856 262 3069 905 IC PCM1804
IC901 263 0896 909 IC NJM2068MD
IC903-905 263 0934 900 IC BA4510F
IC906 262 3069 905 IC PCM1804
IC909,910 262 3105 908 IC SN74AHCT32PW
IC911 262 2517 908 IC SN74LV08APW
IC951 263 0896 909 IC NJM2068MD
IC953-955 263 0934 900 IC BA4510F
IC956 262 3069 905 IC PCM1804
IC958 263 1079 903 IC BA033FP
TR101-106 273 0460 905 Transistor KTC2875B
TR107 269 0083 901 Transistor DTA114EK
TR108 269 0082 902 Transistor DTC114EK
TR151 269 0082 902 Transistor DTC114EK
TR152 269 0083 901 Transistor DTA114EK
TR153 269 0082 902 Transistor DTC114EK
TR154 269 0083 901 Transistor DTA114EK
TR157,158 273 0384 900 Transistor 2SC2412K (S)
TR160 273 0384 900 Transistor 2SC2412K (S)
TR201-206 273 0460 905 Transistor KTC2875B
TR207 269 0083 901 Transistor DTA114EK
TR208 269 0082 902 Transistor DTC114EK
TR301-304 273 0460 905 Transistor KTC2875B
TR307 269 0083 901 Transistor DTA114EK
TR308 269 0082 902 Transistor DTC114EK
TR401-404 273 0460 905 Transistor KTC2875B
TR407 269 0083 901 Transistor DTA114EK
TR408 269 0082 902 Transistor DTC114EK
TR503,504 274 0163 904 Transistor 2SD601A
TR505 272 0125 904 Transistor 2SB709A
TR506 273 0384 900 Transistor 2SC2412K (S)
Note: The symbol in the column "Remarks" indicate the following destinations.
EU: U.S.A. model (AVR-5803) E1: Asia model
EC: Canada model (AVR-5803) E1C: China model
E2: Europe model EUT: Taiwan R.O.C. model
To Next Page
