Denon AVR-5803 Service Manual

70
AVR-5803/AVC-A1SR
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks Q'ty
001 0057 030 Vinyl wire for EU,EC 1
203 0689 004 1P SIN-SIN wire 1
473 7002 018 Screw 3x8 CBTS (S)-Z 5
417 0604 002 Radiator 1
C405 255 4232 937 Polypropylene film 1000pF/100V CQ93P2A102J (NH)
for E2,E1,E1C,EUT
C406,407 255 1265 936 Mylar film 0.01uF/50V CQ93M1H103J (B)
C410 255 1265 936 Mylar film 0.01uF/50V CQ93M1H103J (B)
C411-413 255 4232 937 Polypropylene film 1000pF/100V CQ93P2A102J (NH)
for E2,E1,E1C,EUT
C415 255 1265 936 Mylar film 0.01uF/50V CQ93M1H103J (B)
C417 255 1265 936 Mylar film 0.01uF/50V CQ93M1H103J (B)
C419 255 1265 936 Mylar film 0.01uF/50V CQ93M1H103J (B)
C420,421 255 4232 937
Polypropylene film 1000pF/100V CQ93P2A102J (NH)
for E2,E1,E1C,EUT
C422 255 1265 936 Mylar film 0.01uF/50V CQ93M1H103J (B)
C507-509 256 1042 903 Metallized 0.1uF/250V CF93A2E104K
C511 255 1265 936 Mylar film 0.01uF/50V CQ93M1H103J (B)
C512 254 4533 947 Electrolytic 330uF/6.3V
CE04W0J331M (SMG/RE3)
OTHER PARTS GROUP Q'ty
CW022 203 2399 017 2P SDN-SDN connector cord 1
CW023 203 2418 008 2P SDN-SDN connector cord 1
CW024 203 2400 016 2P SDN-3T lug wire 1
CW025 203 2401 015 2P SDN-3T lug wire 1
CW026 203 2400 016 2P SDN-3T lug wire 1
CW038 203 5237 008 3P SDN-SDN connector cord 1
CW071 205 0942 022 7P connector socket (TUC-P) 1
CW081,082 205 0885 095 8P connector socket (TUC-P) 2
CW102 205 0885 053 10P connector socket (TUC-P) 1
CW933,934 203 5237 011 3P SDN-SDN connector cord 2
CW935 203 5225 007 3P SAN-SAN connector cord 1
CW936 203 5235 013 3P SDN-3T lug wire 1
CW937 203 5236 012 3P SDN-3T lug wire 1
CW938 203 5235 013 3P SDN-3T lug wire 1
CW939 203 5236 012 3P SDN-3T lug wire 1
CX075 205 0343 074 7P connector base (KR-PH) 1
JK401 205 1202 004 6P SP terminal for EU,EC 1
JK401 205 1201 005 4P SP terminal for E2,E1,E1C,EUT 1
JK402 205 1202 004 6P SP terminal 1
JK403 205 1201 005 4P SP terminal 1
JK404 205 1202 004 6P SP terminal for EU,EC 1
JK404 205 1201 005 4P SP terminal for E2,E1,E1C,EUT 1
TP501 205 0190 036 3P NH connector base 1
W421 203 0688 005 1P SIN-SIN wire 1
W422 203 0688 018 1P SIN-SIN wire 1
W508-513 205 0864 003 M3 Screw terminal 6
W514-516 205 1034 023 M3 Screw terminal 3
W517,518 205 1034 010 M3 Screw terminal 2
001 0057 027 Vinyl wire for EU,EC 2
