Denon AVR-5803 Service Manual

8
AVR-5803/AVC-A1SR
Front Chassis, Primary P.W.B., H/P P.W.B.
1. Remove 6 screws
&
.
2. Detach the Front Chassis by pulling upward to release 4
hooks.
3. Remove 3 screws
20
and snap plate, then detach the
H/P P.W.B.
Front Chassis
Hook
Hook
&
Snap Plate
H/P P.W.B.
&
20
20
