84
AVR-5803/AVC-A1SR
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks Q'ty
CX096 205 0884 038 9P connector base (TUC-P) 1
CX107 205 0884 054 10P connector base (TUC-P) 1
CX127 205 0375 026 12P connector base (KR-PH) 1
CX136 205 0375 039 13P connector base (KR-PH) 1
CX502 205 1153 001 9P S sub connector 1
CX831-836 205 0343 032 3P connector base (KR-PH) 6
CX838 205 0343 032 3P connector base (KR-PH) 1
CX971 205 0343 074 7P connector base (KR-PH) 1
CX981 205 0343 087 8P connector base (KR-PH) 1
CX985 205 0884 096 8P connector base (TUC-P) 1
CY034 205 0406 034 3P connector base (KR-PH) 1
CY088 205 1228 004 8P FJ connector base 1
CY105 205 0375 000 10P connector base (KR-PH) 1
CY108 205 0375 000 10P connector base (KR-PH) 1
CY112 205 0375 013 11P connector base (KR-PH) 1
FB201 235 0049 900 Beads inductor for EU,EC 1
FB501-505 235 0147 909 EMI filter BLM21PG221SN1 5
FB507-509 235 0147 909 EMI filter BLM21PG221SN1 3
JK101-104 204 8513 007 6P pin jack (S-GND) 4
JK105 204 8514 006 4P pin jack (S-GND) 1
JK301-303 204 8515 005 4P pin jack (S-GND) 3
JK304,305 204 8512 011 1P pin jack (GOLD) 2
JK501 204 8289 001 DC Power jack 1
JK502,503 204 8260 004 Mini jack 2
JK504 204 8649 007 Mini jack (RD) 1
JK901-904 204 8607 007 3P pin jack (S-GND) 4
RL101 214 0223 004 Relay (EC2-24N35) 1
RL901-908 214 0223 004 Relay (EC2-24N35) 8
RL910 214 0223 004 Relay (EC2-24N35) 1
SW501 212 0408 001 Slide switch 1
TP101,102 205 0133 035 3 P NH connector base 2
TP201,202 205 0133 035 3 P NH connector base 2
TP301,302 205 0133 035 3 P NH connector base 2
TP402 205 0133 035 3 P NH connector base 1
W502 205 1034 007 M3 Screw terminal 1
C501-503 254 4305 900 Electrolytic 0.1uF/50V CE04W1H0R1M (SRE)
C504 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J
C505 257 0511 904 Ceramic chip 0.01uF/50V CK73F1H103Z
C506 254 4306 925 Electrolytic 10uF/50V CE04W1H100M (SRE)
C507 257 0512 903 Ceramic chip 0.1uF/25V CK73F1E104Z
C508 254 4299 964 Electrolytic 47uF/16V CE04W1C470M (SRE)
C509 254 4305 900 Electrolytic 0.1uF/50V CE04W1H0R1M (SRE)
C510 257 0511 904 Ceramic chip 0.01uF/50V CK73F1H103Z
C511 254 4305 900 Electrolytic 0.1uF/50V CE04W1H0R1M (SRE)
C513 254 4305 968 Electrolytic 1uF/50V CE04W1H010M (SRE)
C515 257 0511 904 Ceramic chip 0.01uF/50V CK73F1H103Z
C516-518 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J
C519 257 0516 954 Ceramic chip 0.1uF/25V CK73B1E104K
C522 257 0516 954 Ceramic chip 0.1uF/25V CK73B1E104K
C523 257 0512 903 Ceramic chip 0.1uF/25V CK73F1E104Z
C525 257 0516 954 Ceramic chip 0.1uF/25V CK73B1E104K
C526,527 257 0511 917 Ceramic chip 0.022uF/50V CK73F1H223Z
C912 257 0516 941 Ceramic chip 0.047uF/25V CK73B1E473K
C913 254 4524 943 Electrolytic 1uF/50V CE04W1H010M (SMG/RE3)
C914 256 1059 996 Metallized 1uF/50V CF93A1H105J (JL)
C915 257 0516 954 Ceramic chip 0.1uF/25V CK73B1E104K
C916 257 0516 941 Ceramic chip 0.047uF/25V CK73B1E473K
C961 257 0512 903 Ceramic chip 0.1uF/25V CK73F1E104Z
C962 254 4524 943 Electrolytic 1uF/50V CE04W1H010M (SMG/RE3)
C963-966 257 0512 903 Ceramic chip 0.1uF/25V CK73F1E104Z
OTHER PARTS GROUP Q'ty
AS101 205 0452 017 Style pin 1
CW042 205 0885 082 4P connector socket (TUC-P) 1
CW047 205 0885 082 4P connector socket (TUC-P) 1
CW049 205 0885 082 4P connector socket (TUC-P) 1
CW051,052 205 0885 008 5P connector socket (TUC-P) 2
CW076-079 205 0942 022 7P connector socket (TUC-P) 4
CW086,087 205 0885 095 8P connector socket (TUC-P) 2
CW089 205 0885 095 8P connector socket (TUC-P) 1
CW090 205 0885 037 9P connector socket (TUC-P) 1
CW096,097 205 0885 037 9P connector socket (TUC-P) 2
CW106,107 205 0885 053 10P connector socket (TUC-P) 2
CW113,114 205 0885 066 11P connector socket (TUC-P) 2
CW976-979 205 0942 022 7P connector socket (TUC-P) 4
CW985-987 205 0885 095 8P connector socket (TUC-P) 3
CX031 205 0343 032 3P connector base (KR-PH) for EU,EC 1
CX032 205 0321 038 3P connector base (RED) 1
CX042 205 0884 083 4P connector base (TUC-P) 1
CX047-049 205 0884 083 4P connector base (TUC-P) 3
CX052 205 0884 009 5P connector base (TUC-P) 1
CX072 205 0343 074 7P connector base (KR-PH) 1
CX080 205 0884 096 8P connector base (TUC-P) 1
CX095 205 0343 090 9P connector base (KR-PH) 1
