Denon AVR-5803 Service Manual

93
AVR-5803/AVC-A1SR
Ref. No. Part No. Part Name Remarks Q'ty
32 412 2741 052 P.W.B. holder (H=22) 2
33 449 0080 076 Edging (CE-012S) 2
34 449 0096 086 Edging for EU,EC 1
35 412 4607 107 Trans plate for EU,EC 1
35 412 4607 110 Trans plate for E2,E1,E1C,EUT 1
36 412 2741 010 P.W.B. holder (H=6) 9
37 414 0905 003 Shield plate (T) 1
38 254 6219 007 Electrolytic 33000uF/71V C503,504 2
39 203 5238 007 3C cord Ass'y L=320 2
40 203 5238 010 3C cord Ass'y L=450 2
41 414 0905 016 Shield plate (T) 1
42 204 2928 009 9P PH-PH connector cord CN095 1
43 204 6356 062 13P KR-KR ribbon 175 CN136 1
44 204 6613 019 12P PH-PH connector cord CN127 1
45 203 5094 076 3P PH-PH connector cord CN032 1
46 203 5283 007 3P PH-PH connector cord CN034 1
47 412 4695 106 Trans support 1
48 414 0906 109 Shield plate (F) 1
49 412 2814 044 Card spacer (L=6) 11
50 204 6657 004 15P PH-PH connector cord CN154 1
51 204 6730 002 14P PH-PH connector cord CN142 1
52 204 6731 001 12P PH-PH connector cord CN122 1
53 203 6585 005 4P PH-PH connector cord CN043 1
54 204 2929 008 10P PH-PH connector cord CN104 1
55 204 6353 049 12P KR-KR ribbon 125 CN126 1
56 414 0899 106 Shield plate (DSP) 1
57 204 2552 006 10P KR-KR ribbon 70 CN108 1
58 204 2870 005 10P PH-PH connector cord CN105 1
59 204 6652 009 11P PH-PH connector cord CN112 1
60 105 1377 008 Bottom cover for EU,EC 1
60 105 1377 011 Bottom cover for E2,E1,E1C,EUT 1
61 513 8266 009 Dangerous mark for EU,EC 2
62 146 2088 119 Foot Ass'y 4
63 417 0627 005 Radiator for EU,EC 1
63 417 0627 018 Radiator for E2,E1,E1C,EUT 1
64 273 0457 002 Transistor 2SC5099 (O/P/Y) TR603,607 2
65 271 0298 003 Transistor 2SA1907 (O/P/Y) (LF) TR602,606,604 3
66 412 4608 229 Radiator bracket (L) for EU,EC 1
66 412 4608 232 Radiator bracket (L) for E2,E1,E1C,EUT 1
67 412 4609 228 Radiator bracket (R) for EU,EC 1
67 412 4609 231 Radiator bracket (R) for E2,E1,E1C,EUT 1
68 414 0904 208 Earth plate (TU) for EU,EC 1
69 204 0378 088 6P KR-KR ribbon 225 CN067 1
70 415 9044 007 Insulating sheet 1
71 271 0220 000 Transistor 2SA1493 (O/Y) TR605 1
72 415 0655 039 UL tube (12.7) BK 2
73 417 0594 206 Radiator for EU,EC 4
73 417 0594 219 Radiator for E2,E1,E1C,EUT 4
74 412 4702 002 Radiator support for EU,EC 2
74 412 4702 015 Radiator support for E2,E1,E1C,EUT 2
75 417 0595 108 CU plate 2
76 271 0296 005 Transistor MP1715 7
77 273 0452 007 Transistor MN1715 7
77-1 − Mica sheet Accessories for transistor 14
Ref. No. Part No. Part Name Remarks Q'ty
78 412 4610 107 Radiator bracket (A) for EU,EC 2
78 412 4610 110 Radiator bracket (A) for E2,E1,E1C,EUT 2
79 412 4611 106 Radiator bracket (B) for EU,EC 2
79 412 4611 119 Radiator bracket (B) for E2,E1,E1C,EUT 2
80 412 4248 003 P.W.B. bracket (D) 2
81 233 6409 001 Main trans (583E3) for EU,EC,EUT 1
81 233 6412 001 Main trans (A1SRE1E2) for E2,E1 1
81 233 6415 008 Main trans (A1SRE1C) for E1C 1
82 513 3333 005 Label (trans) 1
83 414 0902 006 Shield cover (B) for EU,EC 1
83 414 0902 019 Shield cover (B) for E2,E1,E1C,EUT 1
84 412 4697 007 Fan bracket (L) for EU,EC 1
84 412 4697 010 Fan bracket (L) for E2,E1,E1C,EUT 1
85 412 4698 006 Fan bracket (R) for EU,EC 1
85 412 4698 019 Fan bracket (R) for E2,E1,E1C,EUT 1
86 421 0749 005 Fan (80x80) 24V 2
87 414 0908 000 Fan plate for EU,EC 2
87 414 0908 013 Fan plate for E2,E1,E1C,EUT 2
88 461 0413 009 Rubber sheet 130x6x6 1
89 144 2711 341 Front panel Ass'y for EU,EC 1
89 144 2711 338 Front panel Ass'y Black model for E2 1
89 144 2711 325 Front panel Ass'y Gold model for E2,E1,E1C,EUT 1
90 341 0051 002 Clamp magnet 1
91 421 0763 007 Gear damper 1
92 144 2718 001 Inner panel Ass'y Black model 1
92 144 2718 014 Inner panel Ass'y Gold model 1
93 412 4617 207 Inner bracket 1
94 144 2714 131 Door for EU,EC 1
94 144 2714 160 Door Black model for E2 1
94 144 2714 157 Door Gold model for E2,E1,E1C,EUT 1
95 401 0188 206 Hinge (L) Black model 1
95 401 0188 219 Hinge (L) Gold model 1
96 401 0189 205 Hinge (R) Black model 1
96 401 0189 218 Hinge (R) Gold model 1
97 441 1929 200 Catch plate 1
98 146 2194 100 FLD frame Ass'y Black model 1
98 146 2194 113 FLD frame Ass'y Gold model 1
99 412 4177 006 Volume bracket 1
100 009 0191 000 29P FFC cable 1
101 415 0849 007 Safety sheet (A) 1
102 415 0850 009 Safety sheet (B) 1
103 112 0828 019 Knob Ass'y (M) Black model 1
103 112 0828 006 Knob Ass'y (M) Gold model 1
104 113 1792 105 Power knob Ass'y Black model 1
104 113 1792 118 Power knob Ass'y Gold model 1
105 112 0773 106 Knob Ass'y (F) Black model 1
105 112 0773 119 Knob Ass'y (F) Gold model 1
106 112 0787 037 Knob (MARU) Ass'y Black model 2
106 112 0787 024 Knob (MARU) Ass'y Gold model 2
107 461 0501 005 Rubber sheet 5
108 144 2716 100 Side cover Black model 2
108 144 2716 113 Side cover Gold model 2
109 412 4620 003 Screw bracket for EU,EC 2
109 412 4620 016 Screw bracket for E2,E1,E1C,EUT 2
