Making the input settings (Input Setup)
Setting items Setting contents
Input Assign(Component)
Assign input sources to input
connectors.
Component : The
DVD HDP TV SAT/CBL VCR DVR V.AUX
input sources are assigned to the component video input connectors as
shown below.
COMP1 (Component video 1 input connector) / COMP2 (Component
video 2 input connector)
None : Do not assign the component video input connectors to the currently
selected input source.
bUpon purchase, the settings of the different input sources are as shown
below.
Input
source
DVD HDP TV SAT/CBL VCR DVR V.AUX
Default
setting
COMP1 None None None None COMP2 None
●
●
iPod Dock
Change the input source to
which the control dock for
iPod is assigned.
The control dock for iPod can be assigned to the
DVD SAT/CBL VCR
DVR V.AUX
input sources.
Assign : Assign the currently selected input source to the Control Dock for
iPod input.
None : Do not assign the currently selected input source to the Control Dock
for iPod input.
• With the default settings, the control dock for iPod can be used
connected to the VCR (iPod) connector.
• Even if “iPod Dock” is set to “Assign”, if AVR-590 and control dock
for iPod are not connected, the input is used as the normal input
source.
Setting items Setting contents
Input Assign(HDMI)
Assign input sources to input
connectors.
HDMI : The
DVD HDP TV SAT/CBL VCR DVR V.AUX
input
sources are assigned to the HDMI input connectors as shown below.
HDMI1 / HDMI2 / HDMI3
None : Do not assign an HDMI input connector to the currently selected
input source.
bUpon purchase, the settings of the different input sources are as shown
below.
Input
source
DVD HDP TV SAT/CBL VCR DVR V.AUX
Default
setting
HDMI1 HDMI2 None HDMI3 None None None
•When HDMI is assigned to an input source, the audio signal switches
to HDMI along with the video signal. To use with the digital audio
input connectors assigned, set menu “Input Mode” (vpage 32) to
“Digital”.
• When the AVR-590 and TV are connected with an HDMI cable, if the
TV is not compatible with HDMI audio signal playback, only the video
signals are output to the monitor.
• The audio signals input from the analog, digital and EXT. IN connectors
are not output to the TV.
NOTE
When “HDMI Control” is set to “ON”, HDMI cannot be assigned to “TV”
at the “HDMI” settings (vpage 27).
•
•
Input Assign(Digital)
Assign input sources to input
connectors.
Digital : The
DVD HDP TV SAT/CBL VCR DVR V.AUX
input
sources are assigned to the digital audio input connectors as shown
below.
C1 (COAXIAL) / O1 (OPT1) / O2 (OPT2)
None ： Do not assign a digital input connector to the currently selected
input source.
bUpon purchase, the settings of the different input sources are as shown
below.
Input source DVD HDP TV SAT/CBL VCR
Default setting None None OPT1 COAXIAL None
Input source
DVR V.AUX
Default setting OPT2 None
•
•
Changing the Input Sources Assigned to the Input Connectors
(Assign)
Default settings are underlined.
Settings
: Moves the cursor (Up/Down/Left/Right)
: Decision the setting
: Return to previous menu
Remote control
operation buttons
:
Displaying the menu
Cancel the menu

Denon AVR-590 Specifications

General

Number of Channels	5.1
HDMI Inputs	3
HDMI Outputs	1
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Tuner Bands	AM/FM
Preset Station Qty	56
Surround System Class	5.1 channel
HDMI Switching	Yes
Width	434 mm
Frequency Response	10 Hz - 100 kHz
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby Pro Logic II
DTS Technologies	DTS 96/24, DTS Neo:6
Audio D/A Converter	24-bit / 192kHz
Tuner Frequency Range	FM: 87.5-108 MHz, AM: 522-1611 kHz
