Denon AVR-791 User Manual

58
ENGLISH
Remote control operation
buttons
Move the cursor
(Up/Down/Left/Right)
Confirm the setting Return to previous menu
Manual Setup
Setting items Setting details
Quick Select Name
(Continued)
Template : The display name can be changed by selecting “Operation”
and “Device Name” from the previously set templates.
1. Use ui to select the name of the Quick Select setting you want to
change, then press ENTER.
2. Use ui to select “Template”, then press ENTER.
3. Use ui to select “Operation”, then press ENTER.
• Watch / Listen to / Play / For
4. Use uio p to select “Device Name”, then press ENTER.
• BD / DVD / TV / Cable TV / Satellite / DVR / VCR / iPod / V.AUX
/ LD / Movie (When “Operation” is selected to “Watch”.)
• CD / TUNER / iPod / MD / Tape / Music (When “Operation” is
selected to “Listen to”.)
• PC / Game (When “Operation” is selected to “Play”.)
• Father / Mother / Son / Daughter / Brother / Sister / Grandfather /
Grandmother / Me (When “Operation” is selected to “For”.)
Default : The changed“Quick Select Name” is returned to the default
setting.
• No : Do not reset to the defaults.
• Yes : Reset to the defaults.
Zone Rename
Change the display title of
each zone to one you prefer.
• Up to 10 characters can be input.
• For character input, see page 41.
Default : The changed display names are reset to the defaults.
• No : Do not reset to the defaults.
• Yes : Reset to the defaults.
Display
Adjust the display
brightness of this unit.
Bright : Normal display brightness.
Dim : Reduced display brightness.
Dark : Very low display brightness.
OFF : Turns the display off.
Buttons on the main unit can be used for
operations.
Each time DIMMER is pressed, the
setting is changed as shown below.
Bright Dim
DarkOFF
Setting items Setting details
Setup Lock
Protect settings from
inadvertent change.
ON : Turn protection on.
OFF : Turn protection off.
When canceling the setting, set “Setup Lock” to “OFF”.
NOTE
When “Setup Lock” is set to “ON”, the settings listed below can no
longer be changed. Also, “SETUP LOCKED!” is displayed if you attempt
to operate related settings.
· Menu operations · Dynamic Volume™
· RESTORER · Channel Level
· MultEQ
®
· Dynamic EQ
®

Denon AVR-791 Specifications

General

Number of Channels	7.1
HDMI Inputs	4
HDMI Outputs	1
Audyssey Technologies	Audyssey MultEQ, Audyssey Dynamic Volume, Audyssey Dynamic EQ
4K Pass-Through	No
Signal-To-Noise Ratio	100 dB
HDMI Switching	Yes
Input Sensitivity	200 mV
THD	0.08%
Surround Sound Effects	Yes
Digital Sound Processor (DSP)	Yes
DSP Preset Qty	7
Tuner Bands	AM/FM
Preset Station Qty	56
Auto Preset Memory	Yes
HDMI Pass-Through	Yes
Frequency Response	10Hz-100kHz
Power Output	90 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Dolby Technologies	Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS Neo:6
Response Bandwidth	10 - 100000 Hz
Input Impedance	47 kΩ
Audio D/A Converter	24-bit / 192kHz
DSP Presets	Rock Arena, Jazz Club, Mono Movie, Matrix, Virtual, Game
Tuning Range	AM: 520 - 1710 kHz, FM: 87.5 - 108 MHz
Connector Type	HDMI
Amplifier Output Details	90W x 7 (8 ohms, 20Hz-20kHz, 0.08% THD)
Video Conversion	Yes (Composite to HDMI)
