• Speaker system layout
Basic system layout
• The following is an example of the basic layout for a system consisting of eight speaker systems and a television monitor:
Subwoofer Center speaker system
Surround speaker systems
Surround back speaker systems
Front speaker systems
Set these at the sides of the TV or screen with
their front surfaces as flush with the front of the
screen as possible.
Before setting up the system
1
2
Check that all the connections are correct, then turn on the main unit’s power.
Setup will not be possible when the unit is set to Pure Direct ON, or when the headphones are plugged in. Therefore, please cancel the
mode or reverse the condition.
Display the System Setup Menu.
(Remote control unit)
NOTES:
• The System Setup menu composition is of a layered design that includes the related items below the large table title as contained in the tables of Pages 18 and
19.
• Wherever your position in System Setup, one more press of the System Setup button permits a move to one level higher.
