24
Check of the measurement results
1
Select the items.
The measurement results of each item can be checked here.
(Remote control unit)
Sp Config.Check
*Auto Setup
2
Press the ENTER button and display the verification
screen.
(Remote control unit)
[Speaker Config. Check] [Delay Time Check] [Channel Level Check]
3
If the check ends, press the ENTER button again.
(Remote control unit)
Select from the following three items based on the
measurement results.
• Set with the checked measurement value.
• Perform the measurement again.
• Cancel the checked measurement value.
4
(Remote control unit)
When the “Store” is selected, all parameters are stored up .
When the “Retry” is selected, it measures again.
5
(Remote control unit)
NOTE:
• When measurements have been made using the
measurement microphone, speakers with a built-
in filter such as subwoofers might be set with a
value that differs from the physical distance
because of the internal electrical delay.
To Next Page
