113
AVR-2809CI / AVR-2809 / AVR-989 / AVC-2809
R752-765 00D2442671901 RS14B3D100JNBST(S)
R768-771 00D2442052960 RS14B3A221JNBST(S)
VR401-407 00D2116159908 V06PB102T(3318F-1-102A)
CAPACITORS GROUP
C401 00D2544804906 CE04W2A101MT(RA3)
C402-408 00D2544583971 CE04W1H470MT(ROB) E2, E1C, JP
C402-408 00D2544802908 CE04W1J101MT(RA3) EU, 989EU, EC
C416-429 00D2544586949 CE04W2A100MT(RA3)
C704 00D2544722981 CE04W1H100MT(GR)
C706 nsp CK73B1H103KT (1608) +1608
C707 00D2544577945 CE04W1C101MT(RA3)
C708 nsp CK73B1E104KT +1608
C710 00D2544716926 CE04W0J331MT(GR)
C714 nsp CK73B1E104KT +1608
C715 00D2544716926 CE04W0J331MT(GR)
C716 00D2544802911 CE04W1J100MT(RA3)
C717-721 00D2544577958 CE04W1C221MT(RA3) E2, E1C, JP
C717-721 00D2544802911 CE04W1J100MT(RA3) EU, 989EU, EC
C722 00D2544802911 CE04W1J100MT(RA3)
C723-729 nsp 0.1UF,J,N,50V
C730 00D2561042903 CF93A2E104KT
C731,732 00D2546277007 CE68W1E822M(DL) E2, E1C, JP
C731,732 00D2546258000 CE68W1V822M EU, 989EU, EC
C733-741 nsp 0.001UF,J,M,50V
C742-750 nsp 0.0047UF,J,M,50V EU, 989EU, EC, JP
C742-750 nsp 0.047UF,J,N,50V E2, E1C
C754,755 nsp 0.1UF,J,N,50V
C756 00D2561042903 CF93A2E104KT
C757 nsp 0.1UF,J,N,50V E2, E1C, JP
C757 00D2544586978 CE04W2A010MT(RA3) EU, 989EU, EC
C758,759 134050062012D CE68W==153M(LAO)BR E2, E1C, JP *
C758,759 134050062005D CE68W==153M(LAO) EU, 989EU, EC *
C760,761 00D2561042903 CF93A2E104KT
C762 00D2544586978 CE04W2A010MT(RA3) EU, 989EU, EC
C762 00MDF15104351 0.1UF,J,N,50V E2, E1C, JP
OTHERS PARTS GROUP
CX034 nsp 3P NH CONNECTOR BASE
CX054 nsp 5P EH CONNECTOR BASE
CX063 nsp 6P NH CONNECTOR BASE
CX074 nsp 7P CON.BASE(TUC-P)
CX082 nsp 8P NH CONNECTOR BASE
CX091 nsp 9P CON.BASE TUC-P
CX115 nsp 11P CON.BASE(KR-PH)
CX409-415 nsp 3P 50mm JC-SCN
CX515 nsp 5P VH CONNECTOR BASE
CX712-718 nsp 7P CON.BASE(TUC-P)
CY041 nsp 4P PH-SAN CON.CORD
CY074 nsp 7P CON.SOCKET(TUC-P
CY075 nsp 7P CON.BASE(TUC-P)
z F701,702 00D2061094066 FUSE(233)T4AL125V EU, 989EU, EC, JP
z F701,702 00D2061096051 FUSE(218)T4AL250V E2, E1C
FF701,702 nsp FUSE CLIP(TAPE)
FH701,702 nsp FUSE CLIP(TAPE)
JK401 00D2051251000 6P SP TERMINAL(V0)
Ref. No. Part No. Part Name Remarks Q'ty New
