Denon AVR-989 Service Manual

112
AVR-2809CI / AVR-2809 / AVR-989 / AVC-2809
PARTS LIST OF P.W.B. UNIT
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
EU (AVR-2809 ): U.S.A. model 989EU (AVR-989): U.S.A. model EC (AVR-2809) :Canada model
E2 (AVR-2809) : Europe model E1C (AVC-2809) : China model JP (AVC-2809) : Japan mode
8U-110030E POWER AMP P.W.B. UNIT ASS'Y (for EU, 989EU, EC model)
8U-110030G POWER AMP P.W.B. UNIT ASS'Y (for E2, E1C model)
8U-110030J POWER AMP P.W.B. UNIT ASS'Y (for JP model)
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC701 00D2631100063 KIA7809API-U/P
IC702,703 00D2631100021 KIA7812API-U/P
IC704,705 00D2631099022 KIA7912PI-U/P
IC706 00D2631293006 KIA7818API-U/P
IC707 00D2631100034 KIA7815API-U/P
TR401 00D2710301903 KTA1268-BL-AT/P
TR402-408 00D2730495006 2SC3964
TR423-429 00D2730458904 KTC3200-BL-AT/P
TR702 00D2690192902 KRC102S-RTK/P (10K-10K)
TR703 00D2690184907 KRA102S-RTK/P (10K-10K)
TR705 00D2730458904 KTC3200-BL-AT/P
TR706 00D2690192902 KRC102S-RTK/P (10K-10K)
TR708 00D2690184907 KRA102S-RTK/P (10K-10K)
TR709 00D2710312905 KTA1504S-GR-RTK/P
TR714 00D2690192902 KRC102S-RTK/P (10K-10K)
TR715 00D2690184907 KRA102S-RTK/P (10K-10K)
TR716 00D2730464901 KTC3875S-GR-RTK/P
TR718 00D2730464901 KTC3875S-GR-RTK/P
TR720 00D2690192902 KRC102S-RTK/P (10K-10K)
TR721 00D2690184907 KRA102S-RTK/P (10K-10K)
TR722 00D2710312905 KTA1504S-GR-RTK/P
TR723 00D2730464901 KTC3875S-GR-RTK/P
TR724 00D2690192902 KRC102S-RTK/P (10K-10K)
TR726 00D2690184907 KRA102S-RTK/P (10K-10K)
TR732 00D2690192902 KRC102S-RTK/P (10K-10K)
TR733 00D2690184907 KRA102S-RTK/P (10K-10K)
TR737 00D2730464901 KTC3875S-GR-RTK/P
TR738 00D2710312905 KTA1504S-GR-RTK/P
TR739 00D2730464901 KTC3875S-GR-RTK/P
D401-421 00D2760401905 1SS133T77 (TAPE)
D702-713 00D2760401905 1SS133T77 (TAPE)
D714,715 00D2760338007 S4VB20F
D716 00D2760401905 1SS133T77 (TAPE)
D717 00D2760855001 D3SB20-7103
D718,719 00D2760401905 1SS133T77 (TAPE)
D721 00D2760401905 1SS133T77 (TAPE)
D722 00D2760704903 1SR35-400A(T93X)
D723 00D2760401905 1SS133T77 (TAPE)
ZD401-414 00D2760643970 MTZJ4.7A T77
RESISTORS GROUP
R422 00D2442051961 RS14B3A101JNBST(S)
R423 00D2412387940 RD14B2E4R7JNBST
R438-451 00D2412375981 RD14B2E220JNBST
R452-479 00D2442671956 RS14B3DR47JNBST(S)
R706,707 123050001000S RW99=3H0R1K
