AVR-2809CI/AVR-989/AVR-2809/AVC-2809
(2) Remove the screws.（ねじをはずす。）
Top view
ً
UCON JUNCTION UNIT
PRIM/CPU SUPPLY UNIT
POWER UNIT
EU model
Top view
ً
UCON JUNCTION UNIT
PRIM/CPU SUPPLY UNIT
POWER UNIT
EC, E2, E1C, JP model
Please refer to "EXPLODED VIEW" for the disassembly method of PRIM/CPU SUPPLY UNIT ASSY.
PRIM/CPUSUPPLYUNITASSY のはずしかたは "EXPLODEDVIEW" を参照してください。
