AVR-2809CI / AVR-2809 / AVR-989 /AVC-2809
2.6. COMPONENTOUTOutputNG
COMPONENT OUT Output NG.
※ When checking operation, select
DVD for the function.
(COMPONENT1 Input)
Checking the video convert ON/OFF settings.
Video convert ON Video convert OFF
Input
CVBS
Input
S
I n p u t
COMPONENT
I n p u t
CVBS
Input
S
Input
COMPONENT
O P Q No output No output Q
2.6. COMPONENTOUT出力 NG
COMPONENTOUT出力 NG ※ 動作を確認する時はファンクショ
ンを DVD に選択してください。
(COMPONENT1入力 )
ﾋﾞﾃﾞｵｺﾝﾊﾞｰﾄON/OFFの設定確認
ﾋﾞﾃﾞｵｺﾝﾊﾞｰﾄON ﾋﾞﾃﾞｵｺﾝﾊﾞｰﾄOFF
入力
CVBS
入力
S
入力 
COMPONENT
入力 
CVBS
入力
S
入力 
COMPONENT
O へ P へ Q へ 出力されません 出力されません Q へ
