2.7. HDMI OUT Output NG
HDMI OUT Output NG.
※ When checking operation, select
DVD for the function.
(COMPONENT1 Input)
Checking the video convert ON/OFF settings.
Video convert ON Video convert OFF
I n p u t
CVBS
I n p u t
S
Input
COMPONENT
Input
HDMI
Input
CVBS
Input
S
Input
COMPONENT
I n p u t
HDMI
R S No output
To troubleshooting 3.HDMI/DVI.
1080p Input? YES No output
T
2.7. HDMIOUT出力 NG
HDMIOUT出力 NG ※ 動作を確認する時はファンクショ
ンを DVD に選択してください。
(COMPONENT1入力 )
ﾋﾞﾃﾞｵｺﾝﾊﾞｰﾄON/OFFの設定確認
ﾋﾞﾃﾞｵｺﾝﾊﾞｰﾄON ﾋﾞﾃﾞｵｺﾝﾊﾞｰﾄOFF
入 力 
CVBS
入 力 
S
入力 
COMPONENT
入 力 
HDMI
入 力 
CVBS
入 力 
S
入力 
COMPONENT
入 力 
HDMI
R へ S へ 出力されません
3.HDMI/DVI のﾄﾗﾌﾞﾙｼｭｰﾃｨﾝｸﾞへ
1080p入力？
YES
出力されません
Tへ
