2. DIGITALPCBASSY
Proceeding: CABINETTOP
→
DIGITALPCBASSY
(1) Removethescrews.
(2) Removethescrews.
Disconnect the connector wires and FFC.
Shooting direction: A
CN205
CN202FFC
CN90
CN95
DIGITAL PCB
