Rear panel
See the page indicated in parentheses ( ).
q
r
wio u ty e
q Speaker terminals (SPEAKERS) ············································· (76)
w Power cord ··············································································· (19)
e Video connectors (VIDEO) ·········································· (13, 14, 15)
r HDMI connectors ································································· (9, 10)
t Network connector (NETWORK) ··········································· (18)
y Digital audio connectors (DIGITAL AUDIO) ···················· (13, 14)
u PRE OUT connector ································································· (76)
i Analog audio connectors (AUDIO) ·································· (14, 15)
o FM/AM antenna terminals (ANTENNA) ································ (17)
NOTE
Do not touch the inner pins of the connectors on the rear panel.
Electrostatic discharge may cause permanent damage to the unit.
