Denon AVR-S650H Service Manual

1.4. Error display
See the table below for descriptions of the displayed errors and countermeasures for these.
If multiple errors occur, only one item is displayed.
The priority order is
w
,
e
,
r
,
q
.
Condition States Display TROUBLE SHOOTING
q
Firm Check
NG
The model name, brand name and region information written in the rmware are compared
to the region settings in the PCB. This error is displayed if the information does not match.
" ▲ " is displayed as the rst character if the rmware is not correct (see the illustrations on
the right).
FIRM ERROR
–
M:*************
–
Main FBL :**.**
–
DSP :**.**
–
Audio PLD:**.**
–
PIMG :********
• Check the resistor for setting the region [R7581, R7582, DIGI-
TAL PCB].
• Write the rmware for the correct region.
PIMG Error indication
• Check the circuits around the Logic [IC722] and SFROM
[IC723]. If there appear to be no problems, [IC722] or [IC723]
is faulty.
w
DIR NG
This error is displayed if there is no response from the DIR.
DIR ERROR 01
• Check the DIR [IC761, DIGITAL PCB] and surrounding circuits.
e
DSP NG
Boot error 1 (After reset the DSP, DSP_Flag0 port is "Low")
DSP ERROR 01
• Check the DSP [IC781, DIGITAL PCB] and surrounding cir-
cuits.
Boot error 2 (After reset the DSP, DSP initialization is not completed)
DSP ERROR 02
(Unused)
DSP ERROR 03
Command error 1 (After sending the command to the DSP, DSP_Flag0 port is "Low".)
DSP ERROR 04
Command error 2 (After sending the command to the DSP, MCU received "COMMAND ER-
ROR".)
DSP ERROR 05
Command error 3 (After sending the command to the DSP, MCU did not receive "COMMAND
SUCCESS".)
DSP ERROR 06
IDL error 1 (Before receiving IDL, "COMMAND BYTE" is not cleared.)
DSP ERROR 07
IDL error 2 (MCU received "IDL SERIOUS ERROR".)
DSP ERROR 08
SPI communication error
DSP ERROR 09
r
BACKUP NG
Error occurred in BACKUP. it is an error of the check sum.
BACKUP ERROR
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
108

Denon AVR-S650H Specifications

General

Receiver type	stereo
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.2 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	10 %
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	5
Composite video in	2
USB ports quantity	1
Speakers connectivity type	RCA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Image formats supported	JPEG
HDCP	Yes
Display	VFL
HDCP version	2.3
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby TrueHD
Volume control	Rotary
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	340 W
Package weight	9525 g
Package width	523 mm
Package height	229 mm

Weight and Dimensions

Depth	330 mm
Width	432 mm
Height	152 mm
Weight	7800 g
