Denon AVR-S650H Service Manual

WIRING DIAGRAM
AVR-S650H W IRING D IAGRAM
FRONT PCB
3P
BN131
3P
CN103
3P
H /P PCB
CN104
LED PCB
POWER
5P
USB PCB
BN104
BN12B 1
MAIN PCB
SMPS PCB
D IGITAL PCB
CN751
6P
CN741
6P
BN601
5P
CN823
3P
BN505
7P
2P
CN602
2P
CN601
7P
CN503
AC CORD
FRONT < -> D IGITA L
USB -> D IGITA L
H / P -FRONT
H /P < - MAIN
SMP S-> D IGITAL
SMP S< -AC IN
BN301
5P
CN302
TRANS -> SMP S
TRANS
TRANS -> FRON T
TRANS-> MAIN
TRANS -> REGUL.
CN102
BN101_1
BN101
5P
FUNCTION
ENCOD ER
27P
27P
9P
9P
15P
CN822
REGU L.-> D IGITAL
ANT 1 A NT 2
PCB T O PCB
REG. PCB
64P
CN753
9P
9P
5P
CN813
CN821
CN825
15P
15P
BN502
PCB T O PCB
42P
CN812
CN811
LEGO
MIC
5P
5P
BN12A
BN12B
MIC PCB
15P
BN501
9P
BN826-1
TUN E R
9P
BN826-2
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
38

Denon AVR-S650H Specifications

General

Receiver type	stereo
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.2 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	10 %
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	5
Composite video in	2
USB ports quantity	1
Speakers connectivity type	RCA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Image formats supported	JPEG
HDCP	Yes
Display	VFL
HDCP version	2.3
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby TrueHD
Volume control	Rotary
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	340 W
Package weight	9525 g
Package width	523 mm
Package height	229 mm

Weight and Dimensions

Depth	330 mm
Width	432 mm
Height	152 mm
Weight	7800 g
