Denon AVR-S650H Service Manual

4.2. Power AMP (AMP PCB)
No audio output.
Protection is activated.
Is the power transistor open or short circuited?
2SB1560 / 2SD2390
Is the emitter resistor of the power transistor
open?
0.47 Ω
Is the base resistor of the power transistor open?
4.7 Ω
Are any other transistors faulty?
Are any other resistors faulty?
Turn on the power and, check that the voltage of each part is correct and that there is an idling current.
Replace the power transistor.
Replace the transistor.
Replace the resistor.
Replace the emitter resistor.
Replace the base resistor.
When using the protection pass mode, do not connect speakers to the speaker terminals.
YES
YES
YES
YES
YES
YES
NO
NO
NO
NO
NO
Check the CPU.
4.3. Analog audio
No audio output.
Is a voltage of ± 12V supplied to DIGITAL PCB
[CN823]?
Is there an audio signal in DIGITAL PCB [CN822]?
Reconnect the connectors correctly.
If the malfunctioning channel and function can be identied, check the corresponding signal path.
Repair the ± 12V power supply.
Repair the power amplier.
Is the serial data for electronic volume sent to the
[IC822] of DIGITAL PCB?
NO
YES
NO
YES
NO
YES
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
70

Denon AVR-S650H Specifications

General

Receiver type	stereo
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.2 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	10 %
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	5
Composite video in	2
USB ports quantity	1
Speakers connectivity type	RCA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Image formats supported	JPEG
HDCP	Yes
Display	VFL
HDCP version	2.3
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby TrueHD
Volume control	Rotary
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	340 W
Package weight	9525 g
Package width	523 mm
Package height	229 mm

Weight and Dimensions

Depth	330 mm
Width	432 mm
Height	152 mm
Weight	7800 g
