Denon AVR-S650H Service Manual

FIRMWARE UPDATE PROCEDURE
1. Items necessary for update
Items necessary for update are as follows.
Update Type Needed Part for Update Requirement
Offered / not Offered
Standard Service Equipment
Not offered by D&M
Purchase from D&M Article code Download from SDI
Via USB
USB ash drive (USB 2.0 : Min 1GB)
• We recommend a USB memory device
that has an LED installed.
Formatting FAT16 or FAT 32 X - "Table 1" or "Table 2"
Via OTA
Internet Connection by Broadband Circuit - X - -
Modem - X - -
Router - X - -
Ethernet cable
(CAT-5 or greater is recommended)
- X - -
Table 1
Update download le when the DIGITAL PCB or network module is replaced
Model Name Model Area Download from SDI
AVR-S650H ALL avr_40.prod.update.factory.xxxx.zip
Table 2
Update download le when the rmware is updated (Two les, "HW component" and "LEGO component")
Model Name Model Area
Download from SDI
For HW component For LEGO component
AVR-S650HE3 North America (E3) Product ID : 000101140700 DPMS_AVR-S650HE3_LEGO_xxxx.zip
heos_40.prod_x.xxx.xx.zipAVR-S650HE2 Europe (E2) Product ID : 000101140900 DPMS_AVR-S650HE2_LEGO_xxxx.zip
AVR-S650HE1C China (E1C) Product ID : 000101140800 DPMS_AVR-S650HE1C_LEGO_xxxx.zip
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
135

Denon AVR-S650H Specifications

General

Receiver type	stereo
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.2 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	10 %
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	5
Composite video in	2
USB ports quantity	1
Speakers connectivity type	RCA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Image formats supported	JPEG
HDCP	Yes
Display	VFL
HDCP version	2.3
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby TrueHD
Volume control	Rotary
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	340 W
Package weight	9525 g
Package width	523 mm
Package height	229 mm

Weight and Dimensions

Depth	330 mm
Width	432 mm
Height	152 mm
Weight	7800 g
