Denon AVR-S650H Service Manual

3-3. Operation Info Mode
3-3.1. Actions
This mode enables the unit to display the accumulated operating time, power On count and each
protection count.
3-3.2. Starting up
While holding down buttons "
TUNE +
", "
BAND
" and "
MODE
" simultaneously, press the power button
to turn on the power.
Select the "
4. OP INFO
" using the "
TUNE +/-
" button, then press the "
STATUS
" button then to conrm.
3-3.3. Operations
Press the "
STATUS
" button after starting up this device in Operation Info mode.
The following information is displayed in the following order.
(1) Accumulated operating time
OP Time ______H
↑ Time display
"
STATUS
"
(2) Power On time
P.On Time______
↑ Time display
"
STATUS
"
(3) DC / ASO Protection count
DC:___/ASO:___
"
STATUS
"
(4) Thermal Protection (A/B) count
THM A:___/B:___
"
STATUS
"
(5) Current Protection count
Current:___
"
STATUS
"
(Returns to normal display)
