Denon AVR-S650H Service Manual

6. Clearing the Operation Info
6.1. Actions
• Displays the accumulated operating time of the unit, the number of times the power was switched
on, and the number of occurrences of each protection.
6.2. Operations
Remove all input/output terminals and the AC plug.
Connect the AC plug again and place the product in standby mode.
While holding down buttons "
TUNE +
" and "
MODE
" simultaneously, press the power button to turn on
the power.
PRODUCT MODE P
When "
PRODUCT MODE
" appears on the display, release the button and press the button "power" to
place the product in standby mode.
7. Log Capture feature
7.1. Actions
• Acquires the Network Module log.
• The log is deleted when the Network Module is deleted.
If an error occurs, it is acquired without turning off the power of this unit.
• The log can be copied to a writable USB ash drive.
It can also be sent to a server if this unit is connected to the Internet.
• The log is stored in the root folder of the USB ash drive with the name "logs-<friendlyname>-
<number>.tar.gz".
<friendlyname> indicates the friendly name and <number> indicates the sequence number.
Previous logs on the USB ash drive are not overwritten. The log is encrypted.
7.2. Starting up
While the power is on, hold down buttons "
MOVIE
" and "
MUSIC
" for at least 3 seconds.
7.2.1. If the USB ash drive is connected after starting the unit
(1) The log is written to the USB ash drive and "Storing Logs..." is displayed.
The log is also sent to the server.
Storing Logs...
(2) When a log package is saved to a USB ash drive, "USB SUCCESS" appears in the display for 5
seconds, regardless of whether the upload to the server was successful.
USB SUCCESS
(3) When saving of the log package fails, "USB FAILED" appears in the display for 5 seconds, regardless
of whether the upload to the server was successful.
USB FAILED
7.2.2. When the USB ash drive is not connected after startup, and this
unit is connected to the Internet.
(1) The log is sent to the server and the display shows "Storing Logs..." for 5 seconds.
Storing Logs...
(2) When the log package is uploaded, the ticket numbers "XXXXX" and "Push ENTER" are displayed
until the "Enter" or "Back" button of RC is pressed.
XXXXX Push ENTER
(3) If the log package upload fails, "FAILED" is displayed for 5 seconds.
FAILED
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
117

Denon AVR-S650H Specifications

General

Receiver type	stereo
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.2 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	10 %
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	5
Composite video in	2
USB ports quantity	1
Speakers connectivity type	RCA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Image formats supported	JPEG
HDCP	Yes
Display	VFL
HDCP version	2.3
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby TrueHD
Volume control	Rotary
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	340 W
Package weight	9525 g
Package width	523 mm
Package height	229 mm

Weight and Dimensions

Depth	330 mm
Width	432 mm
Height	152 mm
Weight	7800 g
