Denon AVR-S650H Service Manual

FORMAT: SHARP /DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED, 1=INVERTED /REMOTE ID: 1
SYSTEM ADDRESS (C1 ～ C5) : ００１００ , EXTENSION BIT (C12,C13) : ０１
No. Data (C6
～
C11) Key Name No. Data (C6
～
C11) Key Name
RCSHP0420000
００００００
RCSHP0420016
００００１０
DOLBY PL
II
MUSIC
RCSHP0420001
１０００００
RCSHP0420017
１０００１０
DOLBY PL
RCSHP0420002
０１００００
RCSHP0420018
０１００１０
RCSHP0420003
１１００００
ROCK ARENA RCSHP0420019
１１００１０
RCSHP0420004
００１０００
JAZZ CLUB RCSHP0420020
００１０１０
RCSHP0420005
１０１０００
RCSHP0420021
１０１０１０
RCSHP0420006
０１１０００
MONO MOVIE RCSHP0420022
０１１０１０
RCSHP0420007
１１１０００
MATRIX RCSHP0420023
１１１０１０
RCSHP0420008
０００１００
VIDEO GAME RCSHP0420024
０００１１０
RCSHP0420009
１００１００
VIRTUAL RCSHP0420025
１００１１０
RCSHP0420010
０１０１００
RCSHP0420026
０１０１１０
RCSHP0420011
１１０１００
RCSHP0420027
１１０１１０
RCSHP0420012
００１１００
RCSHP0420028
００１１１０
RCSHP0420013
１０１１００
DTS NEO:6 CINEMA RCSHP0420029
１０１１１０
MultEQ
RCSHP0420014
０１１１００
DTS NEO:6 MUSIC RCSHP0420030
０１１１１０
RCSHP0420015
１１１１００
DOLBY PL
II
CINEMA RCSHP0420031
１１１１１０
No. Data (C6
～
C11) Key Name No. Data (C6
～
C11) Key Name
RCSHP0420032
０００００１
RCSHP0420048
００００１１
RCSHP0420033
１００００１
RCSHP0420049
１０００１１
RCSHP0420034
０１０００１
RCSHP0420050
０１００１１
RCSHP0420035
１１０００１
RCSHP0420051
１１００１１
INPUT MDOE AUTO
RCSHP0420036
００１００１
RCSHP0420052
００１０１１
RCSHP0420037
１０１００１
RCSHP0420053
１０１０１１
RCSHP0420038
０１１００１
RCSHP0420054
０１１０１１
RCSHP0420039
１１１００１
RCSHP0420055
１１１０１１
RCSHP0420040
０００１０１
RCSHP0420056
０００１１１
RCSHP0420041
１００１０１
RCSHP0420057
１００１１１
RCSHP0420042
０１０１０１
RCSHP0420058
０１０１１１
RCSHP0420043
１１０１０１
RCSHP0420059
１１０１１１
RCSHP0420044
００１１０１
RCSHP0420060
００１１１１
RCSHP0420045
１０１１０１
RCSHP0420061
１０１１１１
RCSHP0420046
０１１１０１
RCSHP0420062
０１１１１１
RCSHP0420047
１１１１０１
RCSHP0420063
１１１１１１
FORMAT KASEIKYO
DATA CONSTRUCTION 48bits
DENON CODE Parity GENRE1 (*1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
0 0 1 0 1 0 1 0 0 1 0 0 1 1 0 0 0 0 0 0 * * * *
GENRE2 (*2) Data ID (*3) Parity (*4)
25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
* * * * * * * * * * * * * * * * * * * * * * * *
(*4) Parity :
Delimit of each to 8 bits, and add the 3rd byte and the 4th byte and the 5th byte with modulo 2 (exclu-
sive-OR).
3rd byte ( 17 - 24 bit)
4th byte ( 25 - 32 bit)
5th byte ( 33 - 40 bit)
REMOTE ID SETTING: (default ID 1)
ID No. ZONE/DEVICE
GENRE1 (*1) GENRE2 (*2) ID (*3)
21 22 23 24 25 26 27 28 39 40
1
MAIN ZONE 0 0 1 0 1 0 0 0 0 0 SHARP&K4-1
TUNER 0 0 1 0 1 0 0 0 0 0 SHARP&K4-1
HEOS MUSIC 0 0 1 0 1 1 1 0 0 0 K4-7
2 MAIN ZONE 0 0 1 0 0 1 0 0 1 0 K4-2
TUNER 0 0 1 0 0 1 0 0 1 0 K4-2
HEOS MUSIC 0 0 1 0 0 0 0 1 1 0 K4-8
3 MAIN ZONE 0 0 1 0 0 1 0 0 0 1 K4-2
TUNER 0 0 1 0 0 1 0 0 0 1 K4-2
HEOS MUSIC 0 0 1 0 0 0 0 1 0 1 K4-8
4 MAIN ZONE 0 0 1 0 0 1 0 0 1 1 K4-2
TUNER 0 0 1 0 0 1 0 0 1 1 K4-2
HEOS MUSIC 0 0 1 0 0 0 0 1 1 1 K4-8
MAIN ZONE
REMOTE ID SET: 1
DENON CODE Parity GENRE1 GENRE2
４ ５ ２ ３ ０
4 1
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
0 0 1 0 1 0 1 0 0 1 0 0 1 1 0 0 0 0 0 0 0 0 1 0 1 0 0 0
REMOTE ID SET: 2-4
DENON CODE Parity GENRE1 GENRE2
４ ５ ２ ３ ０
4 2
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
0 0 1 0 1 0 1 0 0 1 0 0 1 1 0 0 0 0 0 0 0 0 1 0 0 1 0 0
No.
Data ID parity
Key Name
29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
RCKSK0410001 1 0 0 0 0 0 0 0 0 0 * * * * * * * * * * ALL POWER ON/OFF
RCKSK0410002 0 1 0 0 0 0 0 0 0 0 * * * * * * * * * * ALL POWER ON
RCKSK0410003 1 1 0 0 0 0 0 0 0 0 * * * * * * * * * * ALL POWER OFF
RCKSK0410005 1 0 1 0 0 0 0 0 0 0 * * * * * * * * * * MAIN ZONE ON/OFF
RCKSK0410006 0 1 1 0 0 0 0 0 0 0 * * * * * * * * * * MAIN ZONE ON
RCKSK0410007 1 1 1 0 0 0 0 0 0 0 * * * * * * * * * * MAIN ZONE OFF
RCKSK0410016 0 0 0 0 1 0 0 0 0 0 * * * * * * * * * * KEY1
RCKSK0410017 1 0 0 0 1 0 0 0 0 0 * * * * * * * * * * KEY2
RCKSK0410018 0 1 0 0 1 0 0 0 0 0 * * * * * * * * * * KEY3
RCKSK0410019 1 1 0 0 1 0 0 0 0 0 * * * * * * * * * * KEY4
RCKSK0410020 0 0 1 0 1 0 0 0 0 0 * * * * * * * * * * KEY5
RCKSK0410021 1 0 1 0 1 0 0 0 0 0 * * * * * * * * * * KEY6
RCKSK0410022 0 1 1 0 1 0 0 0 0 0 * * * * * * * * * * KEY7
RCKSK0410023 1 1 1 0 1 0 0 0 0 0 * * * * * * * * * * KEY8
RCKSK0410024 0 0 0 1 1 0 0 0 0 0 * * * * * * * * * * KEY9
RCKSK0410025 1 0 0 1 1 0 0 0 0 0 * * * * * * * * * * KEY0
RCKSK0410027 1 1 0 1 1 0 0 0 0 0 * * * * * * * *
* * CURSOR UP
RCKSK0410028 0 0 1 1 1 0 0 0 0 0 * * * * * * * * * * CURSOR DOWN
RCKSK0410029 1 0 1 1 1 0 0 0 0 0 * * * * * * * * * * CURSOR LEFT
RCKSK0410030 0 1 1 1 1 0 0 0 0 0 * * * * * * * * * * CURSOR RIGHT
RCKSK0410031 1 1 1 1 1 0 0 0 0 0 * * * * * * * * * * ENTER
RCKSK0410034 0 1 0 0 0 1 0 0 0 0 * * * * * * * * * * RETURN/BACK
RCKSK0410035 1 1 0 0 0 1 0 0 0 0 * * * * * * * * * * SETUP MENU
RCKSK0410036 0 0 1 0 0 1 0 0 0 0 * * * * * * * * * * MEMORY
RCKSK0410042 0 1 0 1 0 1 0 0 0 0 * * * * * * * * * * UPGRADE ID ON
RCKSK0410112 0 0 0 0 1 1 1 0 0 0 * * * * * * * * * * VIDEO SELECT
RCKSK0410292 0 0 1 0 0 1 0 0 1 0 * * * * * * * * * * QUICK SELECT 1
RCKSK0410293 1 0 1 0 0 1 0 0 1 0 * * * * * * * * * * QUICK SELECT 2
RCKSK0410294 0 1 1 0 0 1 0 0 1 0 * * * * * * * * * * QUICK SELECT 3
RCKSK0410295 1 1 1 0 0 1 0 0 1 0 * * * * * * * * * * QUICK SELECT 4
RCKSK0410296 0 0 0 1 0 1 0 0 1 0 * * * * * * * * * * QUICK SELECT 5
RCKSK0410304 0 0 0 0 1 1 0 0 1 0 * * * * * * * * * * STEREO
RCKSK0410305 1 0 0 0 1 1 0 0 1 0 * * * * * * * * * * DIRECT/STEREO
RCKSK0410306 0 1 0 0 1 1 0 0 1 0 * * * * * * * * * * DIRECT
RCKSK0410307 1 1 0 0 1 1 0 0 1 0 * * * * * * * * * * PURE DIRECT
RCKSK0410308 0 0 1 0 1 1 0 0 1 0 * * * * * * * * * * STANDARD
RCKSK0410309 1 0 1 0 1 1 0 0 1 0 * * * * * * * * * * DIRECT
RCKSK0410320 0 0 0 0 0 0 1 0 1 0 * * * * * * * * * * DTS SURROUND
RCKSK0410324 0 0 1 0 0 0 1 0 1 0 * * * * * * * * * * AUTO SOUND
RCKSK0410329 1 0 0 1 0 0 1 0 1 0 * * * * * * * * * * MOVIE SURROUND
RCKSK0410330 0 1 0 1 0 0 1 0 1 0 * * * * * * * * * * MUSIC SURROUND
RCKSK0410331 1 1 0 1 0 0 1 0 1 0 * * * * * * * * * * GAME SURROUND
RCKSK0410332 0 0 1 1 0 0 1 0 1 0 * * * * * * * * * * SOUND MODE toggle (Reverse)
RCKSK0410336 0 0 0 0 1 0 1 0 1 0 * * * * * * * * * * DSP SIMULATION
RCKSK0410337 1 0 0 0 1 0 1 0 1 0 * * * * * * * * * * MULTI CH STEREO
RCKSK0410340 0 0 1 0 1 0 1 0 1 0 * * * * * * * * * * ROCK ARENA
RCKSK0410341 1 0 1 0 1 0 1 0 1 0 * * * * * * * * * * JAZZ CLUB
RCKSK0410343 1 1 1 0 1 0 1 0 1 0 * * * * * * * * * * MONO MOVIE
RCKSK0410344 0 0 0 1 1 0 1 0 1 0 * * * * * * * * * * MATRIX
RCKSK0410345 1 0 0 1 1 0 1 0 1 0 * * * * * * * * * * VIDEO GAME
RCKSK0410346 0 1 0 1 1 0 1 0 1 0 * * * * * * * * * * VIRTUAL
RCKSK0410348 0 0 1 1 1 0 1 0 1 0 * * * * * * * * * * Dolby Atmos ON/OFF
RCKSK0410349 1 0 1 1 1 0 1 0 1 0 * * * * * * * * * * SOUND MODE toggle (Normal)
RCKSK0410352 0 0 0 0 0 1 1 0 1 0 * * * * * * * * * * INPUT MODE SELECT
RCKSK0410353 1 0 0 0 0 1 1 0 1 0 * * * * * * * * * * INPUT MODE:ANALOG
RCKSK0410357 1 0 1 0 0 1 1 0 1 0 * * * * * * * * * * INPUT MODE HDMI
RCKSK0410358 0 1 1 0 0 1 1 0 1 0 * * * * * * * * * * INPUT MODE:AUTO
RCKSK0410359 1 1 1 0 0 1 1 0 1 0 * * * * * * * * * * INPUT MODE DIGITAL
RCKSK0410368 0 0 0 0 1 1 1 0 1 0 * * * * * * * * * * Volume Up
RCKSK0410369 1 0 0 0 1 1 1 0 1 0 * * * * * * * * * * Volume Down
RCKSK0410370 0 1 0 0 1 1 1 0 1 0 * * * * * * * * * * Mute
RCKSK0410372 0 0 1 0 1 1 1 0 1 0 * * * * * * * * * * M.VR PRESET1 (0dB)
RCKSK0410373 1 0 1 0 1 1 1 0 1 0 * * * * * * * * * * M.VR PRESET2 (-20dB)
RCKSK0410374 0 0 1 0 1 1 1 0 1 0 * * * * * * * * * * M.VR PRESET3 (-40dB)
RCKSK0410378 0 1 0 1 1 1 1 0 1 0 * * * * * * * * * * CHANNEL LEVEL
RCKSK0410384 0 0 0 0 0 0 0 1 1 0 * * * * * * * * * * FL LEVEL UP
RCKSK0410385 1 0 0 0 0 0 0 1 1 0 * * * * * * * * * * FL LEVEL DOWN
RCKSK0410386 0 1 0 0 0 0 0 1 1 0 * * * * * * * * * * FR LEVEL UP
RCKSK0410387 1 1 0 0 0 0 0 1 1 0 * * * * * * * * * * FR LEVEL DOWN
RCKSK0410388 0 0 1 0 0 0 0 1 1 0 * * * * * * * * * * C LEVEL UP
RCKSK0410389 1 0 1 0 0 0 0 1 1 0 * * * * * * * * * * C LEVEL DOWN
RCKSK0410390 0 1 1 0 0 0 0 1 1 0 * * * * * * * * * * SW LEVEL UP
RCKSK0410391 1 1 1 0 0 0 0 1 1 0 * * * * * * * * * * SW LEVEL DOWN
RCKSK0410392 0 0 0 1 0 0 0 1 1 0 * * * * * * * * * * SL LEVEL UP
RCKSK0410393 1 0 0 1 0 0 0 1 1 0 * * * * * * * * * * SL LEVEL DOWN
RCKSK0410394 0 1 0 1 0 0 0 1 1 0 * * * * * * * * * * SR LEVEL UP
RCKSK0410395 1 1 0 1 0 0 0 1 1 0 * * * * * * * * * * SR LEVEL DOWN
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
55

Denon AVR-S650H Specifications

General

Receiver type	stereo
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.2 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	10 %
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	5
Composite video in	2
USB ports quantity	1
Speakers connectivity type	RCA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Image formats supported	JPEG
HDCP	Yes
Display	VFL
HDCP version	2.3
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby TrueHD
Volume control	Rotary
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	340 W
Package weight	9525 g
Package width	523 mm
Package height	229 mm

Weight and Dimensions

Depth	330 mm
Width	432 mm
Height	152 mm
Weight	7800 g
