Denon AVR-S650H Service Manual

HEOS MUSIC
REMOTE ID SET: 1
DENON CODE Parity GENRE1 GENRE2
４ ５ ２ ３ ０
4 7
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
0 0 1 0 1 0 1 0 0 1 0 0 1 1 0 0 0 0 0 0 0 0 1 0 1 1 1 0
REMOTE ID SET: 2-4
DENON CODE Parity GENRE1 GENRE2
４ ５ ２ ３ ０
4 8
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
0 0 1 0 1 0 1 0 0 1 0 0 1 1 0 0 0 0 0 0 0 0 1 0 0 0 0 1
No.
Data ID parity Key Name
29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
RCKSK0470027 1 1 0 1 1 0 0 0 0 0 * * * * * * * * * * CURSOR UP
RCKSK0470028 0 0 1 1 1 0 0 0 0 0 * * * * * * * * * * CURSOR DOWN
RCKSK0470029 1 0 1 1 1 0 0 0 0 0 * * * * * * * * * * CURSOR LEFT
RCKSK0470030 0 1 1 1 1 0 0 0 0 0 * * * * * * * * * * CURSOR RIGHT
RCKSK0470031 1 1 1 1 1 0 0 0 0 0 * * * * * * * * * * ENTER
RCKSK0470034 0 1 0 0 0 1 0 0 0 0 * * * * * * * * * * RETURN
RCKSK0470773 1 0 1 0 0 0 0 0 1 1 * * * * * * * * * * PLAY
RCKSK0470774 0 1 1 0 0 0 0 0 1 1 * * * * * * * * * * PAUSE
RCKSK0470775 1 1 1 0 0 0 0 0 1 1 * * * * * * * * * * STOP
RCKSK0470776 0 0 0 1 0 0 0 0 1 1 * * * * * * * * * * SKIP PLUS
RCKSK0470777 1 0 0 1 0 0 0 0 1 1 * * * * * * * * * * SKIP MINUS
RCKSK0470778 0 1 0 1 0 0 0 0 1 1 * * * * * * * * * * REPEAT ONE
RCKSK0470779 1 1 0 1 0 0 0 0 1 1 * * * * * * * * * * REPEAT OFF
RCKSK0470780 0 0 1 1 0 0 0 0 1 1 * * * * * * * * * * RANDOM ON
RCKSK0470781 1 0 1 1 0 0 0 0 1 1 * * * * * * *
* * * RANDOM OFF
RCKSK0470785 1 0 0 0 1 0 0 0 1 1 * * * * * * * * * * REPEAT ALL
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
57

Denon AVR-S650H Specifications

General

Receiver type	stereo
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.2 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	10 %
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	5
Composite video in	2
USB ports quantity	1
Speakers connectivity type	RCA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Image formats supported	JPEG
HDCP	Yes
Display	VFL
HDCP version	2.3
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby TrueHD
Volume control	Rotary
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	340 W
Package weight	9525 g
Package width	523 mm
Package height	229 mm

Weight and Dimensions

Depth	330 mm
Width	432 mm
Height	152 mm
Weight	7800 g
