Denon AVR-S760H User Manual

Adjusting the tone (Tone)
Adjusts the tonal quality of the front speakers.
1
Press OPTION.
An option menu screen is displayed.
0
When the input source is “HEOS Music”, an option menu for
online music is displayed. Select “AVR Options…”, then press
ENTER.
2
Use ui to select “Tone”, then press ENTER.
The “Tone” screen is displayed.
3
Use o p to set the tone control function to on/off.
On: Allow tone adjustment (bass, treble).
Off
(Default):
Playback without tone adjustment.
4
Select “On” in step 3 and press i to select the sound
range to be adjusted.
Bass: Adjust bass.
Treble: Adjust treble.
5
Use o p to adjust the tone, then press ENTER.
-6 dB – +6 dB (Default : 0 dB)
0
“Tone” settings are stored for each input source.
0
This cannot be set when the sound mode is set to “Direct”.
0
This item cannot be set when “Dynamic EQ” is set to “On”. (v p. 155)
0
You cannot set this when no audio signal is input or in the menu “HDMI Audio Out”
is set to “TV”. (v p. 159)
Contents Connections Playback Settings Tips Appendix
109
Front panel Display Rear panel Remote Index

Denon AVR-S760H Specifications

General

Channels	7.2
HDMI Inputs	6
HDMI Outputs	1
HDMI Version	2.1
HDCP Support	2.3
eARC	Yes
Dolby Atmos	Yes
DTS:X	Yes
Dolby Atmos Height Virtualization	Yes
DTS Virtual:X	Yes
Auto Calibration	Audyssey MultEQ
Wi-Fi	Yes
Bluetooth	Yes
AirPlay 2	Yes
HEOS	Yes
Phono Input	Yes
USB Input	Yes
Ethernet Port	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Power Output	75W per channel (8 ohms, 20Hz-20kHz, THD: 0.08%, 2ch driven)
HDR Support	Dolby Vision, HLG
Dimensions	17.1 x 13.3 x 6 inches (434 x 339 x 151 mm)
