Example connections when using top middle speakers

This 7.1-channel surround system is the same as a basic 5.1-channel system but with top middle speakers.

FL FR

SL SR

TML TMR

Set “Assign Mode” to “Top Middle” in the menu. (v p. 183)

SW C SR SLFLFR

TMR TML
