Denon AVR-S760H User Manual

o
Dialog Control
Adjust the volume of dialog in movies, vocals in music, etc. so these
can be heard more easily.
0 – 6 (Default : 0)
0
This can be set when a DTS:X signal that is compatible with the Dialog Control
function is input.
o
Low Frequency
Adjust the low frequency effects level (LFE).
-10 dB – 0 dB (Default: 0 dB)
0
This can be set when the LFE signal is included in the input signal.
0
This item can be selected when a Dolby Digital or DTS signal or DVD-Audio is
played.
0
For proper playback of the different sources, we recommend setting to the
values below.
0
Dolby Digital sources: 0 dB
0
DTS movie sources: 0 dB
0
DTS music sources: -10 dB
o
Center Spread
Center Spread expands the center channel signal to left and right front
speakers to create a wider frontal audio image for the listener. It is
optimized and designed primary for playback of stereo music content.
On: Use “Center Spread”.
Off
(Default):
Do not use “Center Spread”.
0
You can set this when sound mode is “Dolby Surround”.
Contents Connections Playback Settings Tips Appendix
149
Front panel Display Rear panel Remote Index

Denon AVR-S760H Specifications

General

Channels	7.2
HDMI Inputs	6
HDMI Outputs	1
HDMI Version	2.1
HDCP Support	2.3
eARC	Yes
Dolby Atmos	Yes
DTS:X	Yes
Dolby Atmos Height Virtualization	Yes
DTS Virtual:X	Yes
Auto Calibration	Audyssey MultEQ
Wi-Fi	Yes
Bluetooth	Yes
AirPlay 2	Yes
HEOS	Yes
Phono Input	Yes
USB Input	Yes
Ethernet Port	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Power Output	75W per channel (8 ohms, 20Hz-20kHz, THD: 0.08%, 2ch driven)
HDR Support	Dolby Vision, HLG
Dimensions	17.1 x 13.3 x 6 inches (434 x 339 x 151 mm)
