Connecting the speaker cables
Carefully check the left (L) and right (R) channels and + (red) and –
(black) polarities on the speakers being connected to this unit, and be
sure to connect the channels and polarities correctly.
1
Peel off about 3/8 inch (10 mm) of sheathing from the
tip of the speaker cable, then either twist the core wire
tightly or terminate it.
.
2
Turn the speaker terminal counterclockwise to loosen it.
.
3
Insert the speaker cable’s core wire to the hilt into the
speaker terminal.
.
4
Turn the speaker terminal clockwise to tighten it.
.
o
Connecting the subwoofer
Use a subwoofer cable to connect the subwoofer. Two subwoofers can
be connected to this unit.
The same signal is output from the respective subwoofer terminals.
.
SW1 SW2
Contents
Connections Playback Settings Tips Appendix
36
Front panel Display Rear panel Remote Index

Denon AVR-S760H Specifications

General

Channels	7.2
HDMI Inputs	6
HDMI Outputs	1
HDMI Version	2.1
HDCP Support	2.3
eARC	Yes
Dolby Atmos	Yes
DTS:X	Yes
Dolby Atmos Height Virtualization	Yes
DTS Virtual:X	Yes
Auto Calibration	Audyssey MultEQ
Wi-Fi	Yes
Bluetooth	Yes
AirPlay 2	Yes
HEOS	Yes
Phono Input	Yes
USB Input	Yes
Ethernet Port	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Power Output	75W per channel (8 ohms, 20Hz-20kHz, THD: 0.08%, 2ch driven)
HDR Support	Dolby Vision, HLG
Dimensions	17.1 x 13.3 x 6 inches (434 x 339 x 151 mm)
