Denon AVR-S760H User Manual

Setting items Detailed items Description Page
.
Inputs
Input Assign Changes input connector assignment and the audio input mode. 168
Source Rename Changes the display name for input source. 171
Hide Sources Removes from the display input sources that are not used. 171
Source Level Adjusts the playback level of the audio input. 171
.
Speakers
Audyssey
®
Setup
The acoustic characteristics of the connected speakers and listening room are
measured and the optimum settings are made automatically.
172
Manual Setup
Sets up the speakers manually or changes Audyssey
®
Setup settings.
183
.
Network
Information Displays network information. 193
Connection Selects whether to connect the home network to a wireless LAN or a wired LAN. 193
Settings Used for manually setting the IP address. 195
Network Control Enables network communication in standby power mode. 197
Friendly Name The “Friendly Name” is the name of this unit displayed on the network. You can change
the Friendly Name according to your preferences.
197
Diagnostics Used to check the network connection. 198
AirPlay Settings for Apple AirPlay. 198
Wi-Fi and Bluetooth Toggles power to the Wi-Fi and Bluetooth radios. 199
Contents Connections Playback Settings Tips Appendix
143
Front panel Display Rear panel Remote Index

Denon AVR-S760H Specifications

General

Channels	7.2
HDMI Inputs	6
HDMI Outputs	1
HDMI Version	2.1
HDCP Support	2.3
eARC	Yes
Dolby Atmos	Yes
DTS:X	Yes
Dolby Atmos Height Virtualization	Yes
DTS Virtual:X	Yes
Auto Calibration	Audyssey MultEQ
Wi-Fi	Yes
Bluetooth	Yes
AirPlay 2	Yes
HEOS	Yes
Phono Input	Yes
USB Input	Yes
Ethernet Port	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Power Output	75W per channel (8 ohms, 20Hz-20kHz, THD: 0.08%, 2ch driven)
HDR Support	Dolby Vision, HLG
Dimensions	17.1 x 13.3 x 6 inches (434 x 339 x 151 mm)
