Denon AVR-S760H User Manual

.
Q1 Q2 Q3 Q4
Q
9
Q
8
Q
5
Q
6
Q
7
K
Reception band select button (BAND)
This switches the reception band. (v p. 79)
L
Tune mode select button (MODE)
This switches the tuning mode. (v p. 81)
M
DIMMER button
Each press of this switches the brightness of the display. (v p. 207)
N
STATUS button
Each press of this switches the status information that is shown on the
display.
O
Headphones jack (PHONES)
This is used to connect headphones.
When the headphones are plugged into this jack, audio will no longer
be output from the connected speakers or from the SUBWOOFER
connectors.
NOTE
0
To prevent hearing loss, do not raise the volume level excessively when using
headphones.
P
SETUP MIC jack
This is used to connect the supplied Sound calibration microphone.
(v p. 175)
Q
QUICK SELECT buttons
With a single press of any of these buttons, you can call up various
settings you’ve registered to each button such as the input source,
volume level and sound mode settings. (v p. 130)
R
SOUND MODE buttons
These select the sound mode. (v p. 114)
S
USB port (T)
This is used to connect USB storages (such as USB memory devices).
(v p. 58)
Contents
Connections Playback Settings Tips Appendix
18
Front panel Display Rear panel Remote Index

Denon AVR-S760H Specifications

General

Channels	7.2
HDMI Inputs	6
HDMI Outputs	1
HDMI Version	2.1
HDCP Support	2.3
eARC	Yes
Dolby Atmos	Yes
DTS:X	Yes
Dolby Atmos Height Virtualization	Yes
DTS Virtual:X	Yes
Auto Calibration	Audyssey MultEQ
Wi-Fi	Yes
Bluetooth	Yes
AirPlay 2	Yes
HEOS	Yes
Phono Input	Yes
USB Input	Yes
Ethernet Port	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Power Output	75W per channel (8 ohms, 20Hz-20kHz, THD: 0.08%, 2ch driven)
HDR Support	Dolby Vision, HLG
Dimensions	17.1 x 13.3 x 6 inches (434 x 339 x 151 mm)
