Denon AVR-X2600H Series User Manual

Check item(3-13.1.). Check the video output port for failure. :
Check the Monitor 1 output video signal is correct.
After checking the Monitor 1, change the HDMI cable connection from OUT1 to OUT2.
Turn off the AV AMP and turn it on again.
To check under the same conditions, use the same procedure as that for checking Monitor 1 when
checking the Monitor 2 output.
No video signal is output from Monitor 1 only.
No video signal is output from both Monitor 1 and
Monitor 2.
No video signal is output from Monitor 2 only.
Go to check item (3-13.4.).
Go to check item (3-13.2.).
Go to check item (3-13.11.).
Check the output terminal.
3-13. HDMI transmission IC [MN864788] failure detection procedure
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
114
