Denon AVR-X2600H Series User Manual

CENTER, SURROUND, SURR.BCK ch
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
0dBFS = +/-2.8Vpp=1.98Vrms
AVR-S950H/X2600H
LEVEL DIAGRAM
CENTER ch
SURROUND ch
SURR.BCK ch
-2
.0
-
0.
5
=-2
.
5d
B
+30dB
SP OUT
4.23Vrms/8Ω
+
2
9dB
-
2.0
-
0.5+
3
.0=+
0
.5dB
MAX
SI
GNA
L
LE
V
EL
D
O
L
B
Y
LIM
IT
LE
V
E
L
(
AL
Lc
h-
3dB
F
S)
0dBFS
-10dBFS
-20dBFS
-30dBFS
-40dBFS
AK4458
-0.4dB
Differential Out
NJU72343 MAX. OUTPUT 4.2Vrms
＋
＋
SPEAKER
OUT
D
SP
GAIN
ADJ.
AK4458VN
D/A
－
－
＋
P
LD
NJU72343
PREOUT
DD INPUT:-20dBFS 1kHz
DSP OUTPUT:-20dBFS
ANALOG INPUT:200mVrms L+R 1kHz
(MODE:MULTI CH STEREO)
DSP OUTPUT:-23.0dBFS
PREOUT
159mVrms
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
43

Denon AVR-X2600H Series Specifications

General

Channels	7.2
Speaker Impedance	4-16 ohms
HDMI Inputs	8 (1 front)
HDMI Outputs	2
HDCP Support	HDCP 2.3
HDR Support	HDR10, HLG, Dolby Vision
Phono Input	Yes
Digital Audio Inputs	2 Optical, 1 Coaxial
Analog Audio Inputs	4
Bluetooth Version	4.1
Supported Audio File Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Multi-Room Audio	HEOS
Voice Assistant Support	Amazon Alexa, Google Assistant, Apple Siri
Supported Audio Formats	Dolby Atmos, Dolby TrueHD, DTS:X, DTS-HD Master Audio
Power Output per Channel	95W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response	10Hz - 100kHz
Analog Audio Outputs	2
Other Ports	USB, Ethernet
Speaker Connectors	Binding Posts
Wireless Connectivity	Wi-Fi
Internet Radio Services	TuneIn
Video Support	4K/60Hz
Audio Return Channel (ARC)	Yes (eARC)
Weight	9.5 kg
