Denon AVR-X2600H Series User Manual

ZONE2 ch (w/o Source)
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
LINE IN
AVR-S950H/X2600H
LEVEL DIAGRAM
ZONE2(w/o Source)
+15
.
5dB
200mV
+30dB
SP OUT
4.23Vrms/8Ω
+
2
9d
B
LINE IN
＋
SPEAKER
NJU72750
GAIN
ZONE2
NJU72343
PCM5100
D/A
BD3812(AVR-X2600H、SR5014,NR1710）
from
DA SB-ch
PREOUT
150mVrms
＋
-1
7
.5d
B
-
D
S
P
P
L
D
AK5358B
A/D
PCM5100
D/A
MGAIN setting of MASTER VOL 00dB
Bd0.2+ = Bd0.2- )GOLANA(TUO REKAEPS･
･PREOUT(ANALOG) -2.5dB -15.5dB = -17.5dB
① ② ③ ④
①:Basic OFFSET of VOL=0dB
②:-
③:-
-2
.
0dB
NJU72750
HEOS
BT_TX
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
46

Denon AVR-X2600H Series Specifications

General

Channels	7.2
Speaker Impedance	4-16 ohms
HDMI Inputs	8 (1 front)
HDMI Outputs	2
HDCP Support	HDCP 2.3
HDR Support	HDR10, HLG, Dolby Vision
Phono Input	Yes
Digital Audio Inputs	2 Optical, 1 Coaxial
Analog Audio Inputs	4
Bluetooth Version	4.1
Supported Audio File Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Multi-Room Audio	HEOS
Voice Assistant Support	Amazon Alexa, Google Assistant, Apple Siri
Supported Audio Formats	Dolby Atmos, Dolby TrueHD, DTS:X, DTS-HD Master Audio
Power Output per Channel	95W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response	10Hz - 100kHz
Analog Audio Outputs	2
Other Ports	USB, Ethernet
Speaker Connectors	Binding Posts
Wireless Connectivity	Wi-Fi
Internet Radio Services	TuneIn
Video Support	4K/60Hz
Audio Return Channel (ARC)	Yes (eARC)
Weight	9.5 kg
