Denon AVR-X3500H Service Manual

3-4. Operation Info Mode
3-4.1. Actions
This mode enables the unit to display the accumulated operating time, power On count and each
protection count.
3-4.2. Starting up
While holding down buttons "
ZONE2 SOURCE
", "
DIMMER
" and "
STATUS
" simultaneously, press the
power button to turn on the power.
Select the "
4. OP INFO
" using the "
TUNER PRESET CH +/-
" button, then press the "
STATUS
" button
then to conrm.
3-4.3. Operations
Press the "
STATUS
" button after starting up this device in Operation Info mode.
The following information is displayed in the following order.
(1) Accumulated operating time
OP Time ______H
↑ Time display
"
STATUS
"
(2) Power On time
P.On Time______
↑ Time display
"
STATUS
"
(3) DC / ASO Protection count
DC:___/ASO:___
"
STATUS
"
(4) Thermal Protection (A) count
THM A:___
"
STATUS
"
(5) Thermal Protection (E/F) count
THM E:___/F:___
"
STATUS
"
(6) Current Protection count
Current:___
"
STATUS
"
(Returns to normal display)
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
146

Denon AVR-X3500H Specifications

General

Receiver type	Surround
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	215 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Napster, Pandora, Spotify, Tidal, TuneIn, iHeartRadio
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP
HDMI in	8
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Speakers connectivity type	Binding post
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC

Weight and Dimensions

Depth	390 mm
Width	434 mm
Height	167 mm
Weight	10800 g
