Denon AVR-X3500H Service Manual

3. Starting detecting the point of failure
Check item(3.1.).
Check the power supply status and communication status with the CPU of each device.
Start in HDMI Diagnostics mode and follow the procedures below.
(1) Start in HDMI Diagnostics mode
While the power is on, hold down buttons "
TUNER PRESET CH -
" and "
ZONE2 SOURCE
" for at least 3
seconds.
HDMI DIAGNOSTICS
"HDMI DIAGNOSTICS" is displayed.
When the mode has switched, start Hardware Check.
HardwareCheck...
(2-1) Display when an Error Code is displayed.
Err: H1-XX
Alternating display.
Contact support
Check the Error Code table items.
Error Code table
Error Code Check item No. Description
H1-01 Check item (3-1.1.) Communication Error with HDMI Tx [U1001 : MN864787]
H1-02 Check item (3-2.1.) Communication Error with HDMI SW1 [U1003 : MN864788]
H1-03 Check item (3-3.1.) Communication Error with HDMI SW2 [U1000 : MN864788]
H1-05 Check item (3-7.1.) Communication Error with VIDEO DECODER [U2022 : ADV7180]
H1-06 Check item (3-4.1.) Communication Error with GUI IC [U1026 : ADV8003]
H1-08 Check item (3-8.1.) Communication Error with DSP [U1073 : CS49844A]
H1-12 Check item (3-9.1.) Communication Error with DIR [U1040 : PCM9211]
H1-14 Check item (3-5.1.) DDR check Error [U1028, U1029 : A3R12E40DBF-8E]
H1-15 Check item (3-6.1.) Communication Error with GUI ROM [U1027 : W25Q128JVFIQ]
H1-16 Check item (3-10.1.) Communication Error with ARC IC [U1007 : Sil9437]
(2-2) Display when an Error is not detected.
1 Auto Test
Cancel the mode, and proceed to check item (3.2.).
Canceling the selected mode
Press the power button to exit off the power.
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
95

Denon AVR-X3500H Specifications

General

Receiver type	Surround
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	215 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Napster, Pandora, Spotify, Tidal, TuneIn, iHeartRadio
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP
HDMI in	8
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Speakers connectivity type	Binding post
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC

Weight and Dimensions

Depth	390 mm
Width	434 mm
Height	167 mm
Weight	10800 g
